- Page 1 Ins-60005-GD-US Master Controller Installation Guide...
- Page 2 RECEIVING INSPECTION - Remove any traces of packing material from the unit as such debris may create a fire or shock hazard. Unpack the unit with care and inspect for transit damage. If damage is suspected, the unit must not be used or tested, but you should immediately contact Paxton technical support to assist in troubleshooting or to provide return authorization.
- Page 3 Mounting This housing should be fixed to the surface with suitable fasteners; screws and wall plugs are provided for this in the fitting kit. Also provided are cable ties to secure the cabling and a smaller securing screw for the lid.
- Page 4 General purpose inputs (contact closure) GSM/GPRS modem connection and outputs (12V, 0.25A max) Power Supply Fail secure lock * Door 1 Reader/Keypad Diode Door contact 1 Exit button 1 (push to make) † Door 2 Reader/Keypad Tamper switch (cabinet) * For a fail safe lock (maglock), wire 12V-24V to the ‘N.C.
-
Page 5: Led Diagnostics
If you are running a DHCP server on your network then you do not need to configure the communication settings as a static IP address is not required. The section below (Configuring the Paxton BLU Control Master unit) explains how to configure the unit if you do not have a DHCP server. - Page 6 Once the exit button is pressed or the jumper temporarily placed, the lock should release. When using Paxton readers, the reader’s default indication has all the LEDs on. Access granted is denoted with a single flashing Green LED. Access Denied is a single flashing Red LED.
- Page 7 You will not need to do anything with this information at this point. Make a note of how this information is obtained as it will be needed should the wiring label be lost or misplaced. This information may be required by Paxton technical support for diagnostics...
-
Page 8: Firmware Update
Ethernet connection is not present, or fails configuration, the controller will automatically use the GSM/GPRS modem. Note that cellular charges may apply and use of this will require the purchase of the Paxton BLU Modem and license. You may also choose to set the communication method to GSM or Ethernet only, depending on the customer and site requirements. -
Page 9: Specifications
Tip: Remember to always download the latest version of the installer tool to ensure you have the most recent version of firmware to install. You have now completed the initial configuration of the master controller, power cycle the unit and log into your Paxton BLU account (my.paxton-blu.com), go to Help and select Quick Start Guide to assist you in setting up the controller in your customer and site. - Page 10 Environment Operating temperature - Battery limits 0°C - 32 °F 55°C -131 °F Weatherproof Communication Ethernet network speed 10 Mbits/sec 100 Mbits/sec Ethernet bandwidth requirement 200 kbits/sec DHCP support RS485 network speed 115.2 kbits/sec RS845 Dataline 3280.84 ft (100m) between controllers Features Number of Cards...
- Page 12 Made in the UK Ins-60005-GD-US Managed access controller Master 838-501-US/838-601-US © Paxton Ltd 1.0.3 18/08/2017...
