Accessory
The threaded barbed adapter may be cleaned by washing it with a 65%
•
alcohol / water solution. The part must be thoroughly dry before it is re-used.

8.0 SPECIFICATIONS

8.1 Analyzer Specifications

Sensor Type: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Galvanic fuel cell
Measurement Range: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-99.9% Nitrogen
Resolution/Display: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.1%
The three digit LCD indicates values between 0.0 - 99.9% oxygen.
Over range indicated by one decimal point on display located after the first digit.
Accuracy and Linearity: . . . . . . . . ± 1% of full scale at constant temperature, R.H. and
@ 15˚C - 40˚C pressure when calibrated at full scale.
± 3% actual oxygen level over full operating temperature.
Response Time: . . . . . . . . . . . . . . . . . . . .< 15 seconds for 90% step change. (at 25˚C)
Warm-up Time: None required
Operating Temperature: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15˚C - 40˚C (59˚F - 104˚F)
Storage Temperature: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-15˚C - 50˚C (5˚F - 122˚F)
Operating Pressure: . . . . . . . . . . . . . . . . . . . . . . . . . . . Atmospheric pressure to 3psig.
Environmental: . . . . . . . . . . . . . . . . . . General purpose housing equivalent to NEMA 1.
Handi
The + is not waterproof. 0-95% RH, non-condensing.
Warranty: . . . . . . . . . . . . . . . . . . . . Twenty-four months in normal operating conditions.
Power Requirements: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Powered by one internal,
non-replaceable Lithium battery, CR2450.
Power on push button automatically shuts off after 80 seconds time-out.
Electronics rated general purpose;
not for use in hazardous areas or for use with flammable gases.
Weight:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Approx. 3 Ounces
Battery Life: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Approx. 1850 hours (74,000 cycles)
Sample Port: . . . . . . . . . . . . . . . . . . . . . . . M16 x1 Thread with barbed tubing adapter.
Operating Pressure: . . . . . . . . . . . . . . . . . . . . . . . . . . .Atmospheric pressure to 3 psig
Expected Storage Life : . . . . . . . . . . . . . . . . .Two months with freshness seal on sensor.
