Easy Lift
Defi nition of the lift way
1) Check if space and position correspond to the drawing. Check if there is a telephone line.
2) The pit must be clean and levelled.
FIG.1
d
3) Place the frame down into the pit as per attached drawing of the lift. Side "d" is the one with the
protruding tubular sections. Lay the frame down on the pit as per attached drawing, (if any, the pit
depth should be 50 mm) Figure 1.
FIG.3
FIG.2
2
