vimec EASY LIFT Manual

Lifting platform
Hide thumbs Also See for EASY LIFT:

Advertisement

Quick Links

All manuals and user guides at all-guides.com
EASY LIFT- LIFTING PLATFORM
MANUAL CODE
DATE
APPROVED

Advertisement

loading
Need help?

Need help?

Do you have a question about the EASY LIFT and is the answer not in the manual?

Questions and answers

Related Manuals for vimec EASY LIFT

Summary of Contents for vimec EASY LIFT

  • Page 1 All manuals and user guides at all-guides.com EASY LIFT- LIFTING PLATFORM MANUAL CODE DATE APPROVED...
  • Page 2 All manuals and user guides at all-guides.com...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Easy Lift ASSEMBLY INSTRUCTIONS Table of contents Definition of the lift way ................ 2 Installation of the carriage assembly ..............8 Inserting the nuts ................. 14 Lift way and carriage assembly fi nishing ............... 17 Preparation of cables and wiring for upper door fixing ......

  • Page 4: Definition Of The Lift Way

    All manuals and user guides at all-guides.com Easy Lift Defi nition of the lift way 1) Check if space and position correspond to the drawing. Check if there is a telephone line. 2) The pit must be clean and levelled.
  • Page 5 All manuals and user guides at all-guides.com Easy Lift 4) Fix the guide on the LH side in the corner between sides “a” and “d” (Figures 4-5). FIG.4 FIG.5...
  • Page 6 All manuals and user guides at all-guides.com Easy Lift 5) Fix the fi rst side panel (marked “a1” or “c1”, see drawing and Figure 7) to the guide by means of ST6 6.3x16 screws. 6) Fix the fi rst “L”-shaped profi le (marked “a1 or “c1”) closing the panels with ST6.3x16 screws and at the base with 4.2x13 screws (fi gures 7-8-9).
  • Page 7 All manuals and user guides at all-guides.com Easy Lift FIG.10 FIG.11 8) Fix another 2 or 3 panels on the same sides.
  • Page 8 All manuals and user guides at all-guides.com Easy Lift 9) Fix the fi rst panel of the guide side (d1) using ST6.3x16 screws (fi g.12). Put a 30 mm shim under the panel to place it horizontally (0°) (fi g.13).
  • Page 9 All manuals and user guides at all-guides.com Easy Lift FIG.14 10) Fix also the upper panel (fi g. 14) on the side “d” called “d2”.

  • Page 10: Installation Of The Carriage Assembly

    All manuals and user guides at all-guides.com Easy Lift Installation of the carriage assembly. 1) Prepare the platform / machinery unit to be inserted in the guides. FIG.15 2) Remove the sliding guides on the right side of the machinery (fi g 15).
  • Page 11 All manuals and user guides at all-guides.com Easy Lift 3) Now proceed with inserting the machinery, arranging fi rst a support below the platform landing so that the whole structure is raised from the ground thus making assembly easier (fi g. 16/b rif.1), and di- sconnect the safety edge (fi g.16/a).
  • Page 12 All manuals and user guides at all-guides.com Easy Lift FIG.17 4) Now insert the right side guide using ST6.3x14 screws to the lower frame and to the panels of side “d”. 5) Fix the upper cross-beam supporting the worm screw to the guides using special rubber insulators...
  • Page 13 All manuals and user guides at all-guides.com Easy Lift 6) Insert the worm screw in the supporting cross-beam (fi g. 18), then place the bearing needed for manual operation in the top section. FIG.18 7) After inserting the worm screw in the cross-beam, insert the axial bearing (51106), then the shims and fi nally tighten with the special nut (fi g.
  • Page 14 All manuals and user guides at all-guides.com Easy Lift 7) Now fi x the joint to the worm screw and the lever for manual emergency operation (fi g. 20/21). FIG.20 FIG.21...
  • Page 15 All manuals and user guides at all-guides.com Easy Lift 8) Now fi x the sliding blocks on the right guide (fi g. 22). FIG. 22...

  • Page 16: Inserting The Nuts

    All manuals and user guides at all-guides.com Easy Lift Inserting the nuts. 1) Insert the safety nut (fi g. 23/a) in the pulling nut (fi g. 23/b), trying to get them spaced about 7-12 mm apart (fi g. 23/c). FIG.23...
  • Page 17 All manuals and user guides at all-guides.com Easy Lift 2) Fasten the nuts to the pulley using the special pin, and then turn the worm screw to tighten the two parts. (fi g. 24). FIG.24 3) Get the safety microswitch closer to the groove of the speed governor nut (fi g. 25)
  • Page 18 All manuals and user guides at all-guides.com Easy Lift 4) The 11 mm distance between the nuts (see fi g. 23/c) must always be monitored, since it indicates the nut wear level.To make this check easier, shape the attached metal template (fi g. 26). Keep it on the ma- chine (see fi g.27).

  • Page 19: Lift Way And Carriage Assembly Fi Nishing

    All manuals and user guides at all-guides.com Easy Lift Lift way and carriage assembly fi nishing. 1) Fix and check the proper function of the safety edge, both electrically and mechanically (fi g. 27). FIG. 27...
  • Page 20 All manuals and user guides at all-guides.com Easy Lift 2) After fi xing the door frame to the lower level, remove the pallet from under the platform (in manual emergency mode) and complete the assembly of the panels on sides “a”, “b” and “d”...
  • Page 21 All manuals and user guides at all-guides.com Easy Lift FIG.30 FIG.31...
  • Page 22 All manuals and user guides at all-guides.com Easy Lift FIG.32...

  • Page 23: Preparation Of Cables And Wiring For Upper Door Fixing

    All manuals and user guides at all-guides.com Easy Lift Preparation of cables and wiring for upper door fi xing. 1) Prepare the wiring and arrange the fl at cable in the special bracket above the upper cross-beam and in the platform (fi g. 33/b) - (fi g 33/a), so as to fi x the control unit panel connector on the upper door (fi g.
  • Page 24 All manuals and user guides at all-guides.com Easy Lift 2) Wire the fl at cable and the control unit panel on the lower level door as per the wiring diagrams (fi g. 34). FIG.34...
  • Page 25 All manuals and user guides at all-guides.com Easy Lift 3) Start to fi x the upper door once the panels of the guide side and of the other sides have been installed up to the height of the landing (fi g. 35).
  • Page 26 All manuals and user guides at all-guides.com Easy Lift 4) Finally, complete the installation of the panels so that the door frame is secured. FIG.36 5) Carry out the electrical connections to the terminal board connector of the door as per wiring dia- gram.

  • Page 27: Door Shutter Fixing

    All manuals and user guides at all-guides.com Easy Lift Door shutter fi xing 1) The doors are hinged with two pins, the lower one is fi xed, the upper one is retractable and is kept in position by a spring release. Insert the slope, if installed, on the lower door, and then the special shims (fi g.

  • Page 28: Stop Adjustments And Operating Check

    All manuals and user guides at all-guides.com Easy Lift Stop adjustments and operating check 1) After connecting all door and lock cables, check that the contact on the manual emergency operation and on the safety contacts in the pit are working. Also check the functioning of the manual release of the landing door “0”...
  • Page 29 All manuals and user guides at all-guides.com Easy Lift Due fermate FIG. 40 n°53 Stop n°54 Downward slowdown n°58 Upward slowdown 2) Before carrying out the assembly it is necessary to adjust the stop cams: - Downward slowdown microswitch (cable No.54). Lift the platform at about 100 mm from stop “0” and place the cam on the panel side “D”...
  • Page 30 All manuals and user guides at all-guides.com Easy Lift FIG.43 3) Pour the lubricating oil of the worm screw into the special tank. 4) Check the wiring and the working of the safety contacts: - All lock contacts. - Stop push-button in the lift way and on the button strip.

  • Page 31: Panel Closing

    All manuals and user guides at all-guides.com Easy Lift Panel closing FIG.41 1) Fix the roof, if any, and then start fi xing the “U” profi les for central panels. Pay attention that the pro- fi les are properly fi xed, since the carriage assembly will slide on the sides. Proceed with fi xing the central...
  • Page 32 All manuals and user guides at all-guides.com Easy Lift FIG.42 2) When fi xing the central panels, ensure that there is a 10-15 mm space to allow the sliding of the platform (fi g. 43) between the side panel fi xed to the structure (fi g.42/a) and the “U” profi le (fi g.42/b).
  • Page 33 All manuals and user guides at all-guides.com Easy Lift FIG.44 3) Finally, assemble the panel under the platform (fi g.44).
  • Page 34 All manuals and user guides at all-guides.com Easy Lift Installation Easylift Checklist Before installation: Check the available space as per drawing: ........................................Supply: ........................................Telephone line: ........................................After installation: Clean around the platform: ........................................Emergency stop on the platform: ........................................
  • Page 35 All manuals and user guides at all-guides.com EASY LIFT MANUALE...
  • Page 36 All manuals and user guides at all-guides.com...
  • Page 37 All manuals and user guides at all-guides.com...
  • Page 38 All manuals and user guides at all-guides.com Easy Lift.
  • Page 39 All manuals and user guides at all-guides.com Easy Lift...
  • Page 40 All manuals and user guides at all-guides.com Easy Lift.
  • Page 41 All manuals and user guides at all-guides.com...
  • Page 42 All manuals and user guides at all-guides.com...
  • Page 43 All manuals and user guides at all-guides.com...
  • Page 44 All manuals and user guides at all-guides.com...
  • Page 45 All manuals and user guides at all-guides.com °...
  • Page 46 All manuals and user guides at all-guides.com...
  • Page 47 All manuals and user guides at all-guides.com...
  • Page 48 All manuals and user guides at all-guides.com...
  • Page 49 All manuals and user guides at all-guides.com...
  • Page 50 All manuals and user guides at all-guides.com...
  • Page 51 All manuals and user guides at all-guides.com...
  • Page 52 All manuals and user guides at all-guides.com...
  • Page 53 All manuals and user guides at all-guides.com...
  • Page 54 All manuals and user guides at all-guides.com...
  • Page 55 All manuals and user guides at all-guides.com...
  • Page 56 All manuals and user guides at all-guides.com COMPONENT LIST EASY LIFT, 2,2kW...
  • Page 57 All manuals and user guides at all-guides.com...
  • Page 58 All manuals and user guides at all-guides.com EASY LIFT DC WIRING DIAGRAM ALARM AND LIGHT...
  • Page 59 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 60 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 61 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 62 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 63 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT, 2 landings...
  • Page 64 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT, 2 stops omron...
  • Page 65 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT, 2 landings...
  • Page 66 All manuals and user guides at all-guides.com EASY LIFT DC SCHOOLCONTROL...
  • Page 67 All manuals and user guides at all-guides.com EASY LIFT DC WIRING DIAGRAM AUTOMATIC DOOR OPENERS...
  • Page 68 All manuals and user guides at all-guides.com...
  • Page 69 All manuals and user guides at all-guides.com COMPONENT EASY LIFT, 3 landings, overlod protection, 2,2 kW, frequency inverter...
  • Page 70 All manuals and user guides at all-guides.com...
  • Page 71 All manuals and user guides at all-guides.com EASY LIFT DC WIRING DIAGRAM ALARM AND LIGHT...
  • Page 72 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 73 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 74 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 75 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 76 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 77 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT, 3 landings...
  • Page 78 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT, 3 stops...
  • Page 79 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT, 3 landings...
  • Page 80 All manuals and user guides at all-guides.com...
  • Page 81 All manuals and user guides at all-guides.com WIRING DIAGRAM EASY LIFT...
  • Page 82 All manuals and user guides at all-guides.com Landings indicator SAFELINE 1000 Telephone dialler VA03 Speech synthesizer For further information and/or details, please visit the web-site: www.safeline.se...
  • Page 83 All manuals and user guides at all-guides.com...
  • Page 84 All manuals and user guides at all-guides.com...
  • Page 85 All manuals and user guides at all-guides.com...
  • Page 86 All manuals and user guides at all-guides.com...
  • Page 87 All manuals and user guides at all-guides.com...
  • Page 88 All manuals and user guides at all-guides.com...
  • Page 89 All manuals and user guides at all-guides.com...
  • Page 90 All manuals and user guides at all-guides.com...
  • Page 91 All manuals and user guides at all-guides.com...
  • Page 92 All manuals and user guides at all-guides.com...
  • Page 93 All manuals and user guides at all-guides.com...
  • Page 94 All manuals and user guides at all-guides.com 950BM For further information and/or details, please visit the web-site: www. faacgroup.com...
  • Page 95 All manuals and user guides at all-guides.com QUICK START GUIDE Italy Tel: +39 02 32 681 For further information and/or details, please visit the web-site: www.omron.it United Kingdom Tel: +44 (0)870 752 0861 For further information and/or details, please visit the web-site: www.omron.co.uk...
  • Page 96 All manuals and user guides at all-guides.com...
  • Page 97 All manuals and user guides at all-guides.com...
  • Page 98 All manuals and user guides at all-guides.com Via Parri, 7 (I) - 42045 Luzzara (RE) - Tel.0522/970666 r.a. - Fax.0522/970919...
