vimec S10 Original Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

USE AND MAINTENANCE
INSTALLATION INSTRUCTIONS
PARTS CATALOGUE
DATE ____________ APPROVED ____________
VIMEC reserves the right to make modifi cations and changes to its products at any moment in response to developments in technology.
Vimec s.r.l
Via Parri, 7 - 42045 Luzzara - Reggio Emilia- Italy
Tel. + 39 0522 970 666 - Fax. + 39 0522 970919
www.vimec.biz
S10 MODEL
MANUAL CODE
7512001
31/10/2012
Original instructions
Page 03 - 14
Page 15 - 28
Page 29 - 61

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for vimec S10

Summary of Contents for vimec S10

  • Page 1 Page 15 - 28 PARTS CATALOGUE Page 29 - 61 MANUAL CODE 7512001 DATE ____________ APPROVED ____________ 31/10/2012 VIMEC reserves the right to make modifi cations and changes to its products at any moment in response to developments in technology.

  • Page 2: Ec Declaration Of Conformity

    Name: Marco Marchetti Address: Via Parri n.7 , 42045 Luzzara (R.E.) ITALIA - Tel. +39/0522/970666) states on his own responsibility that the vertical lifting platform type: S10 – Serial number: complies with the following Directives: - Directive 2004/108/EEC “Electromagnetic Compatibility”...

  • Page 3: Use And Maintenance

    7512001 7511001 USE AND MAINTENANCE GENERAL CONTENTS 1. Unit and manufacturer identifi cation Page 2. After-Sales Service Page 3. Description of unit Page 4. Intended and improper uses Page 5. Technical data Page 6. Preparing the lift for operation Page 7.
  • Page 4 7512001 7511001 1) UNIT AND MANUFACTURER IDENTIFICATION I - 42045 LUZZARA (RE) Via Parri N° 7 - Tel. 0522 / 970666 TYPE SERIAL Nr. (N°) - - - - YEAR - - - - LOAD (kg) POWER (V / A / Hz) 220 / 6 / 50 LOAD 300 kg...
  • Page 5 3) DESCRIPTION OF THE UNIT FIG.1 3.1) General Description - Fig. 1 The S10 lift is a platform lift designed to trans¬port disabled persons with or without an attendant. It comprises the following: - Upper platform with non-slip surface (Fig. 1/a) - Column group (Fig.
  • Page 6 4) INTENDED AND IMPROPER USES 4.1) Intended Uses The S10 platform lift is a lift system designed for one disabled person, standing or in a wheelchair + atten- dant (if any), who must be trained in the lift’s operation. When using the lift, compliance with the instructions provided on the signs fi tted to it is compulsory.

  • Page 7: Technical Data

    7512001 7511001 5. TECHNICAL DATA - Lifting system Worm screw plus motor and inverter - Operating data Travel direction Up/Down Speed 0.05 m/s Payload See nameplate on unit - Duty cycles Normal duty 20 Cycles/day - Ambient conditions from -5° to +60° C. Humidity 90% max. (use in Temperature bathrooms and swimming-pools is not permit¬ted).
  • Page 8 7512001 7511001 6) PREPARING THE LIFT FOR OPERATION 7.3) Ensure that the load is stable. 6.1) Electrical panel and installation 7.4) Check that there are no foreign bodies underneath the platform. The customer is required to make all necessary mo- difi...
  • Page 9 7512001 7511001 7.8) Use FIG.6 While the platform lift is in motion the wheel¬chair’s brakes must be engaged and if it is electric it must be switched off. Floor controls: The controls must be kept pressed throughout the transit and cut out the lift if released. The fl oor locks and the on-board control panel are only operational if the key has been inserted.
  • Page 10 7512001 7511001 Only use the emergency gate opening keys (Fig. 9/a) FIG.8 when really necessary. - The platform lift may only be used by a person stand¬ing or in a wheelchair, with or without attendant. All other uses are forbidden. 7.10) Recovering the passenger in an emergency Skill level required TO: Trained operator with spe¬cifi...

  • Page 11: Safety Systems

    Use of the platform is only enabled with the correct lock the lift!! status; the unit cannot be used if the gates are open or Call in an authorised VIMEC technician at once. the locks have been tampered with. g) Movement cut-out in the event of obstacles c) Flap The platform is fi...

  • Page 12: Maintenance

    7511001 9) MAINTENANCE Although the lift has of course undergone rigorous testing, VIMEC advices you to have it inspected regularly by technicians. In order to ensure that it provides the best service in complete safety, it must be inspected regularly by our specialist engineers, who will carry out all the operations described below.
  • Page 13 7512001 7511001 9.2) Check and replacement of nuts FIG.11 The two upper and lower nuts coupled to the lead screw and placed in the column, during the machine operation the wear is proportionally to the number of cycles and to the load applied to the platform (people weight). Therefore, it is necessary to replace the nuts after a certain number of cycles.

  • Page 14: Electrical Wiring Diagrams

    Emergency STOP pressed Turn the button in either direction clockwise through 45° Overload cutout tripped Press the reset button Differential circuit-breaker Call a VIMEC authorised tripped technician Gates and locks Close the gates properly Safety gear switch Replace drive bushing...

  • Page 15: Installation Instructions

    7512001 7511001 INSTALLATION INSTRUCTIONS GENERAL CONTENTS 1) Lift supply package Page 16 2) Place of installation Page 16 3) Transport Page 16 4) Installation instructions Page 16 5) Final testing Page 28 6) Operating checks and adjustments Page 28...

  • Page 16: Place Of Installation

    7512001 7511001 1. LIFT SUPPLY PACKAGE 4.1 Wall column assembly for a machine with a stroke under 1600 mm Machine with 1100/1600 mm stroke - Complete platform - Use the eyebolts to remove the column from the - Preassembled column packaging and from the crate (Fig.1/a) and remove - Upper fl...
  • Page 17 7512001 7511001 FIG.3 - Use lifting equipment and slings to move the column to the wall in a vertical position. WARNING: Use a spirit level to check that it is vertical (Fig. 2/a). - Use plugs to fi x the column to the wall by the base connection (Fig.
  • Page 18 7512001 7511001 4.2 Wall assembly of the column for a machine with FIG.6 a stroke above 1600 mm Assemble the connections as follows: With chemical or mechanical plugs: - Fix the basic connection to the wall. - Fix all the other intermediary connections making sure that they are perfectly plumb and aligned with the fi...
  • Page 19 7512001 7511001 FIG.9 - Block the head connection in the wall, checking fi rst if it is perpendicular to the guides. Use the “L” brackets (Fig. 10/a) for wall fi xing and adjust them if necessary. The head connection is already equipped with a motor (Fig.
  • Page 20 7512001 7511001 FIG.12 - Mount the trolley on the column by raising a guide (Fig. 14/a) in order to insert it easily (Fig. 14/b). Once the trolley is inserted, reposition the raised guide and tighten all the bolts. - Screw the “C” guides to the column (Fig. 13/a). - Fix the side casings by placing the spacers (Fig.
  • Page 21 7512001 7511001 4.3 Mounting worm screws and nut screws FIG.15 - Put the screw in the column and cross through the hole in the trolley with the lower part of the screw (Fig. 15/a). - Raise the trolley and lift the screw about 400 mm, (the screw will stick out from the upper support) (Fig.
  • Page 22 7512001 7511001 FIG.18 FIG.20 FIG.19 FIG.21...
  • Page 23 7512001 7511001 - Mount and put the belts in tension (Fig. 22/a). FIG.22 - Mount the braking group using the special support (Fig. 23). FIG.23...
  • Page 24 7512001 7511001 4.4 Mounting the platform FIG.24 - Raise the platform and position it so that the slotted plates coincide with those on the trolley (Fig. 24/a). NOTE: Before fi xing the platform, close the bellows (if present) with straps (Fig. 25/a). This operation makes it easier to mount the platform with bellows, without creating impediments.
  • Page 25 7512001 7511001 FIG.26 - Assemble the edge guards by inserting the tubular ele- ments in the platform holes (Fig. 26/a) and then fi x them on the platform frame with the grub screws (Fig. 26/b). 4.6 Mounting the slide - Using the screws provided, screw the hinges on the slide to the holes on the platform structure (Fig.
  • Page 26 7512001 7511001 4.8 Mounting the 1st fl oor gate FIG.30 - Install the top fl oor gate, comply with the stated mea- surements, and fi x it to the ground using the expansion plugs (Fig. 30/a). 4.9 Electrical wiring - Connect the wiring to the push-button board. - Connect the electrical wiring of the double bottom (if present).
  • Page 27 7512001 7511001 Move the platform to the fl oor using the on-board com- FIG.34 mands. Insert the long casing (Fig. 34/a), previously dismantled, between the platform and column, then fi x it to the “C” profi les using the screws provided. Then fi...

  • Page 28: Final Testing

    7512001 7511001 5) FINAL TESTING The lift system must be tested by skilled staff authorised by VIMEC. Run the lift up and down a few times, checking that: - There is no interference between the platform and the shaft. - There are no unusual vibrations or strange noises.

  • Page 29: Parts Catalogue

    7511001 7512001 PARTS CATALOGUE USO E MANUTENZIONE CONTENTS OF THE CATALOGUE Column Page 30 Casing Page 32 Nuts Page 34 Rails and accessories Page 36 On-board control panel Page 38 Floor control panel Page 40 Lock Page 42 Bellows Page 44 Platform Page 46 Electrical system...
  • Page 30 COLUMN 7512001...
  • Page 32 CASING 7512001...
  • Page 34 NUTS 7512001...
  • Page 36 RAILS AND ACCESSORIES 7512001...
  • Page 42 LOCK 7512001...
  • Page 44 BELLOWS 7512001...
  • Page 46 PLATFORM 7512001...

  • Page 48: Electrical System

    ELECTRICAL SYSTEM 7512001...
  • Page 52 ON-BOARD GUARDS 7512001...
  • Page 54 GATE SPRING 7512001...
  • Page 56 MOTOR-OPERATED GATE 7512001...
  • Page 58 GATE CONTROL BOARD 7512001...
  • Page 60 REMOTE CALL COLUMN 7512001...
