- Page 1 M200 INSTRUCTIONS FOR INSTALLATION AND USE STANDARD INSTALLATION ORIGINAL INSTRUCTIONS COD. 0P5711 VER. 00 REV.07.20...
-
Page 2: Errors List
M200 INDEX TECHNICAL DATA GENERAL INFORMATION and SAFETY PAG 3 PAG 4 PRELIMINARY OPERATIONS PAG 5 ARTICULATED ARM INSTALLATION PAG 6 SLIDING ARM INSTALLATION SLIDING ELBOW ARM INSTALLATION PAG 8 PAG 10 ELECTRICAL CONNECTIONS FIRST STARTUP PAG 12 SELF LEARNING... -
Page 3: Technical Data
TECHNICAL DATA M200 -AUTOMATION FOR SWING DOORS The Automation M200 for hinged doors is designed and produced in accordance to the European standard EN16005.The automation is an electromechanical type designed for indoor installation only. The mechanical and electronic technology guarantees safely the management and synchronization of swing doors with single and double panel. The automation can be used in the pull inward configuration with sliding or elbow arm, and in the push outward configuration with normal arm. -
Page 4: General Information And Safety
Topp srl reserves the right to improve and amend the manual and products described at any time and without notice. • The information contained in this manual was written and checked with the maximum care; however, topp srl has no liability for any errors due to omissions or errors in printing or transcription. -
Page 5: Preliminary Operations
M200 PRELIMINARY OPERATIONS BEFORE STARTING THE INSTALLATION Check the following points: • The structure that will support the automation is sufficiently sturdy • Surface on which the actuator bracket will be fastened is free of distortions. • Care has been taken to eliminate protruding parts of the door •... - Page 6 M200 ARTICULATED PUSHING ARM INSTALLATION COMPONENTS 1- Cover, plastic cover plates and 4 fixing screws 2- Automation M200 3- Fixing plate 4- Automation fitting nuts 5- Articulated arm and extractor cap * 6- Axle extension and corresponding screw (optional) *...
- Page 7 M200 ARTICULATED PUSHING ARM INSTALLATION AUTOMATION INSTALLATION M200 with articulated pushing arm DRILLING HOLES With a suitable drill, make the 6 holes as per the position specifications and insert the 6 anchors in the wall holes Mark the 2 fixing points for the arm...
- Page 8 M200 SLIDING PULLING ARM INSTALLATION COMPONENTS 1- Cover, plastic cover plates and 4 fixing screws 2- Automation M200 3- Fixing plate 4- Automation fitting nuts 5- Sliding arm and extractor cap * 6- Axle extension and corresponding screw (optional) *...
- Page 9 M200 SLIDING PULLING ARM INSTALLATION AUTOMATION INSTALLATION M200 with pulling sliding DRILLING HOLES With a suitable drill, make the 6 holes as per the position specifications and insert the 6 anchors in the wall holes Mark the 2 fixing points for the arm...
- Page 10 M200 SLIDING PULLING ARM INSTALLATION - ELBOW COMPONENTS 1- Cover, plastic cover plates and 4 fixing screws 2- Automation M200 3- Fixing plate 4- Automation fitting nuts 5- Sliding elbow arm and extractor cap * 6- Axle extension and corresponding screw (optional) *...
- Page 11 M200 SLIDING PULLING ARM INSTALLATION - ELBOW AUTOMATION INSTALLATION M200 with pulling sliding arm-elbow DRILLING HOLES With a suitable drill, make the 6 holes as per the position specifications and insert the 6 anchors in the wall holes Mark the 2 fixing points for the arm bracket.
-
Page 12: Electrical Connections
M200 ELECTRICAL CONNECTIONS BEFORE MAKING THE ELECTRICAL CONNECTION OF THE AUTOMATION, CHECK THAT: • The main power supply connected to the automation must comply with the requisites contemplated by the legislation in force in the country of installation, and must have the technical characteristics indicated in tab.2- cap.2.5 and on the rating plate, as well as the “CE”... - Page 13 M200 ELECTRICAL CONNECTIONS PRE-WIRED ELECTRIC CONNECTIONS - POWER SUPPLY CIRCUIT 1 ON-OFF Switch 2 Function selector 3 Led signal/ Near 4 Battery 5 Electronic board 6 Motor 7 Encoder 8 Transformer 9 Filter 10 Fuse 11 Power supply connection instructions for installation...
- Page 14 M200 ELECTRICAL CONNECTIONS - SAFETY SENSORS SAFETY SENSORS CONNECTION, IF THEY ARE PRESENT CONNECTION OF IS6 TOPP SAFETY SENSOR HOTRON SSS-5 CONNECTION OF OPTEX SAFETY SENSORS OPTEX AO EDGE T instructions for installation...
- Page 15 M200 ELECTRICAL CONNECTIONS - SAFETY SENSORS SUPPLEMENTARY SAFETY SENSORS CONNECTION, IF THEY ARE PRESENT CONNECTION OF IS6 TOPP SUPPLEMENTARY SAFETY SENSOR- HOTRON SSS-5 CONNECTION OF OPTEX SUPPLEMENTARY SAFETY SENSORS OPTEX AO EDGE T instructions for installation...
- Page 16 M200 ELECTRICAL CONNECTIONS - RADAR ACTIVATION SENSORS CONNECTION, IF THEY ARE PRESENT ATTIVAZIONE 1 1 7 7 N.O. 1 1 8 8 1 1 9 9 1 1 2 2 2 2 0 0 1 1 3 3 2 2 1 1...
- Page 17 1.Press and hold the <DOWN> key for 5 seconds, the display shows the word “RADIO” blinking on the 7-segment display. 2.If you are using the 4-channel Topp TS1S remote control, press the second button (closed function). To confirm that the remote control has been memorized, the blinking word “RADIO”...
- Page 18 M200 DOUBLE LEAF INSTALLATION DOUBLE LEAF OPERATION Perform the mechanical installation and the electric wiring assuming the two leaves would be independent, following page 6 in presence of articulated arm or page 8 sliding arm or page10 elbow arm. The Double leaf operation has a MASTER and a SLAVE leaf. The MASTER leaf is the first one to OPEN.
- Page 19 A regular maintenance is required to ensure the correct operation of the automation, this maintenance activity may be carried out either by TOPP, in accordance with a specific agreement made with the user, or by the installation technician or by other competent and qual-ified technical personnel in possession of all legal requirements.
- Page 20 M200 LIST OF ERROR MESSAGES AND NOTICES instructions for installation...
- Page 21 M200 CONFIGURATION OF AUTOMATION PARAMETERS CONFIGURATION OF PARAMETERS/FUNCTIONS It is possible to enter the basic parameters using the 7 segment display and the <ENTER> and <DOWN> keys.Press and hold <ENTER> for 5 sec to enter the configuration menu. Press <DOWN> to pass from a parameter to another, press <ENTER>...
- Page 22 M200 CONFIGURATION OF AUTOMATION PARAMETERS val. ref. display parameter description value description *default* SAFETY LOGIC NO with active low test (to GND) Setting with logic of the 4 safety sensors. For values NC with active high test (NC with test 24V)
- Page 23 M200 CONFIGURATION OF AUTOMATION PARAMETERS val. ref. display parameter description value description *default* Resets everything MAINTENANCE Resets only cycle counter Reset only distance 0° ANGLE OF INHIBITION OF 3° OBSTACLE SAFETY SENSOR 6° 9° Blind spot of safety sensor on opening (hinge side): 12°...
- Page 24 M200 CONFIGURATION OF AUTOMATION PARAMETERS val. ref. display parameter description value description *default* 10 s 15 s DOOR OPEN PAUSE TIME. 20 s Regulates the open door pause time after radar 30 s reading. 40 s 60 s 120 s...
- Page 25 M200 CONFIGURATION OF AUTOMATION PARAMETERS val. ref. display parameter description value description *default* FINAL STROKE Increasing the value increases the force. Serves to regulate the closing velocity and facilitate the fastening of the electric lock. ELECTRIC LOCK STATUS CONTROL MODE Absent Perm its control of lock s tatus .
-
Page 26: Arm Removal
M200 ARM REMOVAL Arm removal - Extractor cap 1) Isert the extractor cap by screwing it clockwise. If not already entered 2)Turn the fastening screw anticlockwise so that it pushes on the extractor cap and removes the arm from its seat. - Page 27 M200 DISABLE SPECIAL FUNCTIONS SERVOASSISTED FUNCTION WITH DISABLE USER BUTTON By connecting the external and internal opening buttons as per the following diagram and correctly setting parameter 113 on the board, the door will enter Servo / Push & GO mode. Setting parameter 113 = 3, the Push & GO function is activated with safety sensors activated Setting parameter 113 = 2 the Push &...
- Page 28 M200 EC DECLARATION OF INCORPORATION instructions for installation...
- Page 29 M200 instructions for installation...
- Page 30 M200 instructions for installation...
- Page 31 M200 instructions for installation...
- Page 32 M200 MANUALE DI INSTALLAZIONE AUTOMAZIONE Max capacity 250 Kg Società a socio unico soggetta a direzione e coordinamento di 2 Plus 3 Holding S.p.a. via Galvani 59, 36066 Sandrigo (VI) tel. +39 0444 656700 fax +39 0444 656701 www.topp.it info@topp.it...
