■ CALIBRATION FLOW CHART
LD1*
G
Fine Adjustments ?
LD2
LD3
G
HOLD DOWN 1 – 2 s
MODE
LD1
R
FINE ZERO
LD2
ADJUSTMENT MODE
G
LD3
or
UP DOWN
PRESS
MODE
LD1
R
FINE SPAN
LD2
ADJUSTMENT MODE
LD3
or
UP DOWN
G
PRESS
MODE
LD1*
G
LD2
LD3
POWER ON
I/O Ranging ?
RUN MODE
HOLD DOWN
Once the transmitter
LD1
enters the fine zero
R
adjustment mode,
LD2
the output goes to
R
preadjusted 0%
value regardless LD3
of the present input
signal.
PRESS
Once the transmitter
LD1
enters the fine span
R
adjustment mode,
LD2
the output goes to
preadjusted 100%
value regardless
LD3
R
of the present input
signal.
PRESS
RUN MODE
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
MODE
Control
UP
Buttons
DOWN
> 5s
MODE
Apply simulated 0% input signal.
HOLD DOWN
INPUT
RANGING
MODE
HOLD DOWN
Apply simulated 100% input signal.
MODE
Adjust simulated input until the output meter
shows desired 0% output.
HOLD DOWN
OUTPUT
RANGING
MODE
HOLD DOWN
Adjust simulated input until the output meter
shows desired 100% output.
MODE
When you set 0% or 100% input/output ranges,
keep pressing UP or DOWN button until the
LD1 blinks for approx. 2 seconds and turns off,
which indicates the setup is complete.
If the LED does not change, the entered level may
be inappropriate: e.g. out of usable range.
*For the model M3LR-x/A, the green LED is blinking.
For the model M3LR-x/B, the green LED turns on.
M3LR
Amber LED OFF
A
G Green LED ON
R Red LED Blink
0% INPUT
DOWN
CONFIGURED
100% INPUT
UP
CONFIGURED
0% OUTPUT
DOWN
CONFIGURED
100% OUTPUT
UP
CONFIGURED
EM-2662-A Rev.2 P. 7 / 8
