Communication Cable Connections

Choose a cable/connector to match the specific port being used. Use a network cable to connect
to the Ethernet port. There are at least four serial connection options available to the 1133A. A
special RS-232 cable and adapter are included: RJ-11 phone cable and RJ-11 to DB-9F adapter.
Connection options and cables:
RS-232/485: Standard phone cable and RJ-11 to DB9F cable adapter.
Modem: Standard phone cable.
Ethernet: 10Base-T (RJ-45) to network.
For serial port locations, see Chapter 2 of the manual. Connector pin locations are specified in
Table 3.2 of the Manual. After connecting the appropriate cable, PSCSV must be set up and used
to begin configuring and viewing data.
Setting Up PSCSV
PSCSV is available for download from www.arbiter.com, and is designed to operate under most
Windows operating systems, exclusively for use with the 1133A. Basic functions allow users to
download and export various types of data. More advanced functions and complete configuration
are available with the Login Name of "admin".

Starting PSCSV

1. Download PSCSV from the Arbiter website and install on your computer.
2. Start PSCSV by clicking on the shortcut icon, or using the Start menu.
3. From the PSCSV main window, check for existing connections listed under the
menu item. If none exist, select
Open
Chapter 6, Opening a Connection for further details on the connection procedures.
4. If correct serial port connection names exist, select one and open the connection.
Note 1: an open connection will be recognized by the connection name appearing in the connection
window, and activation of all of the Broadcast Toolbar Icons.
Note 2: When connecting to the 1133A using an optional serial port, either connect the supplied
RJ-11/DB-9F adapter directly to the computer or use a null modem cable between the adapter
and computer.

Security

When a new connection to the 1133A is established, the user is automatically logged in as anon
with no password. In order to gain administration level access, the connected user must log in as
admin with the default password 801n60. Once logged in as admin, the default password should be
changed and as many as 14 additional users can be created. See the operation manual for further
information.
Software
Connection
to establish a new connection. See
New
3
Connection
