JetStream Smart Switch
The front panel of T1600G-18TS (TL-SG2216) is shown as the following figure.
Figure 1-3 Front Panel of T1600G-18TS (TL-SG2216)
The front panel of T1600G-28TS is shown as the following figure.
Figure 1-4 Front Panel of T1600G-28TS
The front panel of T1600G-52TS (TL-SG2452) is shown as the following figure.
Figure 1-5 Front Panel of T1600G-52TS (TL-SG2452)
T1600G-52TS
Smart Switch
PWR
Reset
SYS
Reset
The front panel of T1600G-52PS (TL-SG2452P) is shown as the following figure.
Figure 1-6 Front Panel of T1600G-52PS (TL-SG2452P)
PWR PoE Max
SYS FAN
T1600G-52PS
Speed PoE
Smart PoE Switch
Reset
Reset LED Mode Switch
The front panel of T1700G-28TQ is shown as the following figure.
Figure 1-7 Front Panel of T1700G-28TQ
LEDs
02 Introduction
LEDs Reset
LEDs Reset
LEDs 10/100/1000 Mbps RJ45 Port
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
LEDs
Button
Unit ID LED Reset
10/100/1000 Mbps RJ45 Port
10/100/1000 Mbps RJ45 Port
20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
1000Mbps 10/100Mbps activity Delivering Power Over Budget Fault
Speed PoE
10/100/1000 Mbps RJ45 Port
10/100/1000 Mbps RJ45 Port
SFP Port
SFP Port
F
SFP Port
39 40 41 42 43 44 45 46 47 48 49 50 51 52
F
SFP Port
SFP+ Port
