- Page 1 Built-in Oven OV911TBL Installation and Operating Manual...
-
Page 2: Table Of Contents
CONTENTS Important Notes ------------------------------------------------------------------------------------------------Page 2 Installation Instructions ----------------------------------------------------------------------------------------Page 3 Technical Specification--------------------------------------------------------------------------------------------Page 4 Control Panel -------------------------------------------------------------------------------------------------------Page 4 Oven Operation---------------------------------------------------------------------------------------------------------Page 5 Cooking Function -------------------------------------------------------------------------------------------Page 7 General Advise -----------------------------------------------------------------------------------------------------Page 9 Cooking Time -----------------------------------------------------------------------------------------------------Page 10 Cleaning and Maintenance ------------------------------------------------------------------------------------Page 12 Page 1 Version 1.0 Sept 2018... -
Page 3: Important Notes
Important Notes Dear Customer Thank you for choosing our product. This appliance is easy to use; however please read this handbook carefully before installing and operating it. Herein, you will find the correct method of installation and tips for best use and maintenance of the product. -
Page 4: Installation Instructions
Before connecting to the mains, make sure that: The electricity meter, safety valve, feeding line and socket are adequate to withstand the maximum load required (refer to product data label for maximum load) The supply system is regularly earthed, according to the regulations in force. ... -
Page 5: Technical Specification
When the oven is in operation, the oven door will heat up. Take note of the “Warning! Hot Surface” sign. Make sure children do not go near the oven when it is in use. Technical Specifications Model : OV911TBL Voltage : (220 – 240)Vac Frequency... -
Page 6: Control Panel
Control Panel Setting of Local Time Press to turn the oven on. Display will illuminate and local time will be shown. Press and hold for 3 seconds until the local time is flashing. Adjust the local time by using , and then to confirm selection. -
Page 7: Oven Operation
Oven Operation To select a cooking function, press until the desired cooking function is shown, press to confirm selection. Then press to adjust cooking temperature followed by to confirm and start cooking. symbol will illuminate to show the oven is now heating up to the set temperature. Press to turn the oven chamber light on &... - Page 8 5 seconds again. Symbol will disappear once deactivated. Oven Cooking Functions The OV911TBL oven is an eleven-function oven. The selection between the cooking functions can be done by pressing button on the touch control panel. Defrost – The fan operates without the heating elements. Can be used to defrost frozen food. The required time for defrosting depends on the type and quantity of food, and the room temperature.
- Page 9 in use. The rotisserie can be used with this function. Half Grill – The inner top heating element operates. Provides direct heat to the top surface of the food. It is suitable for small portions of foods, e.g. toast. Keep oven door closed when in use. The rotisserie can be used with this function.
-
Page 10: General Advise
Rotisserie The OV911TBL oven is equipped with a removable multiple skewer rotisserie positioned parallel to the back of the oven. Slide the meat to be cooked into the spit lengthwise, keeping it in place with the adjustable forks. Fix guide “1” to the top of left hand side rack. Slide the rotisseries rod into the hole for the motor shaft (M) on the right hand side of the oven. -
Page 11: Cooking Time
It is advisable to place food into the oven after preheating it. Grill Cooking (the two upper heating elements works) To cook with the grill, pre-heat the oven for about 5 minutes. During grill operation the heat comes from above; and its suitable for thin cuts meat and for toasts. - Page 12 Food Qty.Kg Shelf No. Temp.℃ Pre-heat time in Time in minutes min. Veal cutlet 8--10 Lam cutlet 12--15 Liver 10--12 Chopped meat 12--15 roulades Veal heart 12--15 Roast in the net 20--25 Half-chicken 20--25 Fish filet 12--15 Stuffed tomatoes 10--12 Grilling The 1st guide rail is understood as being the lowest position.
-
Page 13: Cleaning And Maintenance
Cleaning and Maintenance Caution: Prior to cleaning or maintenance, always disconnect the power supply. Make sure a steamer cleaner is not used. Check the oven rubber seal condition on a regular basis. Clean it if necessary. Avoid using abrasive cleaners. Should it be damaged, contact the nearest after sales service centre. - Page 14 5) CLEANING OF OVEN DOOR Clean the glass door by using damp cloth and dry it. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven glass door as they may scratch the surface and cause glass shattering. 6) REMOVING THE OVEN DOOR AND GLASS To make it easier to clean the oven chamber, the oven door could be removed.
- Page 15 Unscrew the clips 1 and 2 located at left and right of the door frame. Lift the middle glass up a bit and remove the middle glass. 8) REPLACING THE OVEN BULB Set the control knob to position “0” and disconnect the oven plug. Unscrew the lamp cover, wash and dry it. Remove the light bulb from its socket, replacing it with another one suitable for high temperature 300°C.
- Page 16 Warning: 1. Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electrical shock. 2. Accessible parts may become hot during use. Young children should be kept away. 3. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
