Summary of Contents for Avenview SW-HDM-4X1
- Page 1 VIDEO WALLS VIDEO PROCESSORS VIDEO MATRIX SWITCHES EXTENDERS SPLITTERS WIRELESS CABLES & ACCESSORIES Control Your Video PRODUCT MANUAL Model: SW-HDM-4X1 4X1 HDMI switcher with IR & RS232 Control...
- Page 2 Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products of Avenview Inc. is strictly prohibited.
-
Page 3: Table Of Contents
INTRODUCTION ..........................3 PACKAGE CONTENTS .........................4 2.2 BEFORE INSTALLATION ........................4 2.3 APPLICATION DIAGRAM ........................5 2.4 PANEL DESCRIPTION ..........................6 2.4.1 I/O PANEL (SWITCHER, SW-HDM-4X1) Front................6 2.4.2 I/O PANEL (SWITCHER, SW-HDM-4X1) Rear................6 2.5 IR REMOTE FUNCTIONS........................7 2.6 RS 232 COMMANDS..........................7 INSTALLATION.............................7 3.1 PC SOFTWARE TOOL..........................8 3.1.1 USING THE SOFTWARE......................8... -
Page 4: Getting Started
• Removal, installation, and set-up service charges. SAfETy GUIDELINES The SW-HDM-4X1, 4X1 HDMI Switcher has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the SW-HDM-4X1 should be used with care. -
Page 5: Regulatory N Otices Federal Communication Commission (Fcc)
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Avenview is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. -
Page 6: Introduction
With IR remote control, front panel button and RS232; this allows users to display any of the 4 sources they choose. Connecting PS3, DVD players, camcorders, or set-top boxes can be easily and simultaneously done with built-in HDCP support; allowing any device to be connected to the SW-HDM-4X1. Features Support HDMI Deep Color... -
Page 7: Package Contents
PACKAGE CONTENTS Before you start the installation of the SW-HDM-4X1, please ensure that the packaging has the listed items below. SW-HDM-4X1 Power Adapter (5VDC 1A) IR Receiver IR Remote PRODUCT USER MANUAL BEFORE INSTALLATION ATTENTION • Place the product on an even and stable surface. If the product falls, it may cause an injury to a person or malfunction. -
Page 8: Application Diagram
APPLICATION DIAGRAM www.avenview.com... -
Page 9: Panel Description
PANEL DESCRIPTION 2.4.1 I/O PANEL (SWITCHER, SW-HDM-4X1) Front RS-232: Connect to a device that has the IR SENSOR: 3.5mm IR Receiver cable for IR ability to send/receive serial commands. signal. Place IR Remote within direct line of site with the IR Receiver. -
Page 10: Ir Remote Functions
2. Connect 1-4 sources to the INPUTS ports of the SW-HDM-4x1via HDMI cable. 3. Connect to a HDTV/Monitor via HDMI cable 4. Plug in 5V 1A DC Power (supplied) to the SW-HDM-4x1. (There is no power switch. Power is supplied when the power adapter is plugged into wall outlet. -
Page 11: Pc Software Tool
Start by downloading and extracting the software from the Avenview website. Connect the controlling PC to the serial port on the SW-HDM-4X1 with a USB to serial adapter cable then, plug in the DC power connecter. Start the software by double-clicking on "HDMI 4x1 switcher.exe". Making sure "RS232" is selected, click on "Scan ComPort". -
Page 12: Specifications
SPECIFICATIONS MODEL NUMBER SW-HDM-4X1 HDMI COMPLIANCE HDMI 1.4 HDCP COMPLIANCE HDCP 1.1 VIDEO BANDWIDTH 6.75 GBPS VIDEO SUPPORT 480P, 720P, 1080I, 1080P, AND VESA RESOLUTIONS TRANSMISSION UP TO 15M/50FT AT 1080P AUDIO SUPPORT SURROUND SOUND (UPTO 7.1 CH) OR STEREO 2CH INPUT TMDS SIGNAL 1.2 VOLTS (PEAK-TO-PEAK) -
Page 13: General Troubleshooting
PIN 5 TMDS DATA1 SHIELD PIN 15 PIN 6 TMDS DATA1– PIN 16 PIN 7 TMDS DATA0+ PIN 17 DDC/CEC GROUND PIN 8 TMDS DATA0 SHIELD PIN 18 +5V POWER PIN 9 TMDS DATA0– PIN 19 HOT PLUG DETECT www.avenview.com... -
Page 14: Warranty Card
PARTS: During the Warranty Period of of THREE (3) YEARS, Avenview will supply new or rebuilt replacements in exchange for defective parts of the product(s) at no cost if the product(s) is determined to have abide by Avenview’s published guidelines. Cost of Parts applicable to product(s) after Warranty Period. For part(s) costs, please contact support@avenview.com. - Page 15 Disclaimer While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of Avenview concerning such products or this documentation, for any interruption of service, loss or interruption of business, loss of anticipatory profits, or for punitive, incidental or consequential damages in connection with the furnishing, performance, or use of the Avenview hardware, software, or other products and documentation provided herein.
