Vex Robotics VEXnet Joystick Setup page 10

Setup
VEXnet Joystick Configuration
2. Press and hold the 6U trigger button.
3. While keeping the 6U trigger button pressed in, use your Allen wrench or paper clip to press in the
internal CONFIG button until the JOYSTICK LED blinks red and green.
© 2011 Carnegie Mellon Robotics Academy / For use with VEX Robotics Systems
in ROBOTC
(cont.)
2. Press and hold the 6U trigger button
3a. Press and the CONFIG button
While still pressing in the 6U trigger button,
use an Allen wrench or paper clip to press in
the CONFIG button.
3b. JOYSTICK LED
Once the JOYSTICK LED begins to blink
red and green, release both the 6U and
CONFIG buttons.
VEX Cortex Configuration over USB
ROBOTC
• 9
