- Page 1 User guide.
-
Page 3: Important Safeguards
Important safeguards. Warning! To avoid the risk of serious injury, carefully read all instructions before operating your NutriBullet Juicer . When using any electrical appliance, basic ™ safety precautions should always be observed, including the following important information. PERSONAL SAFET Y... - Page 4 PRODUCT SAFET Y Do not push food into the feed chute with your fingers This juicer is only designed to or utensils. Only use the food juice fruits and vegetables. pusher provided. Do not place Please refer to the juicing guide your hand or fingers into the to determine the correct speed feed chute when it is attached...
- Page 5 The use of attachments not electrical shock and injury to recommended sold persons, do not immerse the NutriBullet may cause fire, ® juicer, Motor Base, cord or plug electric shock or injury. This juicer in water or any other liquid.
- Page 6 Keep the juicer clean. Refer to care and cleaning section for further information. Vibration can occur during normal operation. If extreme vibration occurs, discontinue call Customer Service. Any maintenance other than cleaning should be performed by an authorized electrician. Do not attempt to repair or service the juicer, contact Customer Service for assistance at...
-
Page 8: Table Of Contents
Important safeguards What’s included Assembly guide Assembly & use Usage instructions ontrol panel Juicing tips Disassembly Care and maintenance Juice and unit storage Troubleshooting guide Replacement parts NutriBullet Juicer Pro™ one-year limited warranty Thank you for purchasing the NutriBullet Juicer Pro™. -
Page 9: What's Included
What’s included. DUAL SIZE 1000 WATT MOTOR PULP BASIN COVER FOOD PUSHER BASE WITH WITH 76 MM FEED LOCKING HANDLE CHUTE 2L PULP BASIN STAINLESS STEEL SIEVE 800 ML JUICE PITCHER WITH NO DRIP SPOUT JUICE PITCHER LID CLEANING BRUSH TWO 350 ML GLASS WITH FROTH SEPARATOR STORAGE BOTTLES... -
Page 10: Assembly Guide
Assembly guide. dual-size food pusher 76 mm feed chute basin cover stainless steel sieve (inside basin) 2L pulp basin locking handle no-drip spout juice pitcher lid multi-speed control panel motor base 800 ml juice pitcher... -
Page 11: Assembly & Use
Assembly & use. Motor Base Pulp Basin Place the Place the on top a dry, level counter top. of the Motor Base. Align the Pulp Basin Ensure the dial is set to the with the Motor “OFF” position and the unit Base so that the spout is is unplugged. - Page 12 Locking Handle Raise the No-Drip Spout Swing the and move it into the “ears” on cover up vertically so that each side of the Basin Cover. it is no longer covering the Locking Handle should juice spout. be in a vertical position and locked into place.
-
Page 13: Usage Instructions
Usage instructions. Gather all of your desired After the juicer is fully ingredients. Wash and assembled, plug the power prepare them for juicing. cord into an outlet. NOTE: If no speed is selected after 10 minutes, the unit will power o . - Page 14 Dual-Size To operate the Select a speed to begin Food Pusher, grip the juicing. The speed selected outer edge of the top of will illuminate on the the pusher with one hand control panel. You may and the bottom of the start at any speed and can pusher with the other hand.
- Page 15 If you are using larger If you are using smaller ingredients, keep the feed ingredients (smaller chute empty (creating a fruits, leafy greens, stalk wider chute) and lock the vegetables like celery or inner pusher back inside carrots), place the outer part the outer pusher.
- Page 16 NOTE: You may alternate Juice will begin to fl ow out between the two chute sizes of the spout and into the (narrow and wide) as you Juice Pitcher, while the are juicing. pulp will be separated and WARNING: Pulp Basin.
- Page 17 To stop juicing, press the speed Pulp Basin When the at which you are currently completely full, it must be juicing. To completely power emptied before continuing o the juicer, press the center juicing. See disassembly power button and wait for the instructions.
-
Page 18: Ontrol Panel
Control panel. MULTI SPEED CONTROL PANEL & JUICING SETTINGS OFF: Power is OFF. If the unit is ON, the center power button will be illuminated. Pressing the center button will turn the unit OFF. LOW: Best for juicing softer fruits and vegetables. -
Page 19: Juicing Tips
Juicing tips. JUICING SPEED SELECTION GUIDE INGREDIENTS SPEEDS SEASONS Apple High All Year Beets High Spring / Summer Blueberry High Winter / Spring / Summer Broccoli High Autumn / Winter / Spring Brussels Sprouts High All Year Cabbage Spring / Summer / Autumn Carrots High Autumn / Winter / Spring... - Page 20 VITAMINS / NUTRIENTS source of quercetin excellent source of folate good source of vitamin C high in vitamin C, high in folate, good source of potassium high in vitamin C, good source of folate high in vitamin C excellent source of vitamin A, good source of vitamin C high in vitamin C, good source of folate good source of vitamin C, good source of vitamin A good source of vitamin C...
- Page 21 PROPER PRODUCE PREP FEED CHUTE Prepare fruit and veggies before Food Pusher Selecting which inserting them into the juicer: to use (narrow or wide) a ects feed chute thickness. If you • Properly clean produce pull out the thinner inner food (rinse with produce wash, or pusher from within the full lukewarm water and apple...
- Page 22 CONSUMING JUICE AND PULP OVERHEATING, SPEED SELECTION, & AUTO SHUT OFF Instead of composting or throwing away the pulp left • If the motor overheats, the over after juicing, you can juicer will turn o . choose to consume it. See our •...
-
Page 23: Disassembly
Disassembly. Ensure the unit is powered Remove the pitcher from “OFF” and unplugged. under the spout. To prevent No-Drip Spout drips use the cover to close the juice spout. Locking Handle Pulp Basin Unlock the Remove the Basin Cover from the Motor Base by from the pulling upwards with the pulling the handle backward... - Page 24 Food Pusher Remove the Lift the Basin Cover lifting it out of the feed chute. vertically o of the Pulp Basin and remove any pulp from the inside of the cover. You may use the fl at end Cleaning Brush of the scrape pulp o of the cover.
-
Page 25: Care And Maintenance
Sieve to soak in best practices. hot water for 30 minutes. Motor Always ensure the All Juicer Pro components Base is unplugged before Motor Base except the you begin assembly, dishwasher safe. You may disassembly, cleaning also hand wash with warm or storage of the unit. -
Page 26: Juice And Unit Storage
Juice & unit storage. Included with your Juicer Pro are some great storage accessories: a Juice Pitcher, two Juice Storage Bottles, and two Freezer Trays. The storage accessories give you For best taste, consume three options for storing juice: fresh juice and pulp within 48 hours of juicing. -
Page 27: Troubleshooting Guide
Troubleshooting guide. PROBLEM: PROBLEM: The power The juicer button flashes three stopped in the middle of times and then remains juicing, and the power illuminated when I select button remains illuminated. a speed. SOLUTION: You have SOLUTION: This means exceeded 10 minutes of that the unit is not properly continuous running time. - Page 28 one (1) year limited replacement warranty statement. If your product becomes YOUR WARRANTY IS SUBJECT TO THE defective due to faulty FOLLOWING CONDITIONS: material or workmanship DO NOT • operate the within a period of 1 appliance with a damaged year from the date of plug or cord, or if the unit has purchase, we warrant to...
- Page 29 PO Box 574 NSMC South Morang Auckland 0745 Victoria 3752 0800 285538 1300 285538 www.bulletbrands.co.nz www.bulletbrands.com.au NutriBullet is a registered trademark of CapBran Holdings, LLC. Copyright © 2020 CapBran Holdings, LLC. All rights reserved. Los Angeles, CA 90025, USA. Made in China.
- Page 32 NutriBullet, LLC | All rights reserved. NutriBullet and the NutriBullet logo are trademarks of CapBran Holdings, LLC registered in the U.S.A. and worldwide. 220-240VAC 50-60Hz 1000W Illustrations may di er from the actual product. We are constantly striving to improve our products, therefore the specifications contained herein are subject to change without notice.
