• The module just powered up.
• There is no LTE coverage in the area. Alarm.com recommends a steady signal level of two or higher for proper
operation of the module.
In Connected Mode, the LED toggles on and off.

LED L5 (yellow)

L5 indicates Z-Wave errors. The possible signals and what they indicate is shown in the following table.
LED pattern
2-blink
5-blink
6-blink
Module states (modes)
There are three module states (modes).
Idle
In Idle Mode, the AC power is up, the battery level is greater than 11.5 volts, and the module is not currently connected
to the Alarm.com servers. This is normal for the module and the most common state.
L1 - Flashes errors, if any.
L2 - Communication with panel.
L3 - Communication with radio unit.
L4 - Signal level (zero to five bars).
https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Panels/Interlogix_Concord/Interlogix_Concord_Inst...
Device Status or Error
No other nodes are in the network
(lasts until a device is added to
the network).
Learn mode error (lasts 60 seconds).
No Home ID present (lasts until the
module connects to Alarm.com and
is configured).
Description
No devices have been added that
can be controlled by the LTE
Module. See above for instructions
on how to add devices.
The device you attempted to add into
a Z-Wave network was
not successfully
added.
When the LTE module first connects
to Alarm.com it is configured with a
necessary unique network ID.
