LED pattern
4-blink
2-blink
Solid
Solid with one blink
LED L3 (green or yellow)
L3 flashes with every communication between the module and its radio unit in Idle Mode, and with every communication
with Alarm.com in Connected Mode. In PowerSave Mode, this LED flashes in unison with LED L2.
LED L4 (green or yellow)
L4 indicates the LTE signal level as a number of flashes (zero to five bars). The number of bars may not correspond to
the bars shown on your cell phone. A level of 5 bars is obtained only in the strongest signal conditions. Signal level is
updated every ten seconds if it fluctuates, or every 30 seconds if it is fairly stable.
If LED L4 is continuously flashing, the module provisioning process is in progress. The signal level indication will resume
after the process completes.
If L4 is not flashing it indicates one of the following states:
• The module is in PowerSave Mode.
https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Panels/Interlogix_Concord/Interlogix_Concord_Inst...
Device status or error
Add mode (lasts 120 seconds or until
a device is added)
Delete mode (lasts 120 seconds or
until a device is deleted)
Successful add node/remove node/
replication (lasts 60 seconds)
Add node attempt failed because
node already in network (lasts 60
seconds)
Description
This mode can add a device to the
local Z-Wave network. Devices
cannot be added to a network if they
are already a part of a
network.
This mode can delete a device from
a Z-Wave network. A device can
only be in one network at a time, and
must receive a "delete" command
before it can be learned into a new
network.
After receiving this signal leave all
devices by the HSPA 3G Module for
one minute. Locks must be left next
to the module for four minutes.
The device is already in a network,
and must be "deleted" before it can
join a new network.
