ECR 4 Kids ELR Series Manual

San Diego, CA 92110 USA
www.ecr4kids.com
Resin Tables
Model #'s : ELR-14405—14407
WARNING:
Adult Assembly Required.
Two adults recommended.
- Contains small parts, sharp points and edges.
- Do not stand, sit, kneel, climb, lean or pull on
unit for support.
- Never leave children unattended.
- Do not place unit near high heat or moisture.
- Adult supervision recommended.
TOOLS INCLUDED
Hex Tool (1)
TOOLS NEEDED
Phillips Screwdriver
BEFORE ASSEMBLING, MAKE SURE YOU HAVE ALL THE PARTS
A
Batch ID Sticker
located on underside
to adjust leg height
1
Install Legs onto Table Frame
Install each Leg (A) onto the Table Top with three Machine Screws (C2)
along with the Split Washers (C1) using a Phillips screwdriver.
Do not use power tools.
Parts List
Legs (4) B
C
C1
Use the Hex Tool
Phillips Screws (8)
Use a Phillips
Screwdriver
Split Washers & Machine Screws (12)
C2
Use a Phillips
Screwdriver
See Next Page
