Boiler Size and Function Guide

KDB-101/131/161/201/251/301GOM+
Pressure Gauge : Indicates the pressure inside the heating pipes. In case the pressure falls
below 49kPa(0.5kgf/cm
matically refill the water to 49~147kPa (0.5~1.5kgf/cm
Water Drain : For a vacation or not at home for a prolonged period of time, to guard
against freezing, the water is excreted through this part.
Pressure Relief Valve : When there is excessive pressure inside the heating pipes, it
automatically excretes the water inside the boiler to maintain optimal
pressure level. In case of long absence from home, to guard against
freezing, the water inside the boiler should be drained.
Heating Water Filter(Strainer) : Filter is built-in to catch any contaminants inside the heating pipes to
2
), open the water replenishing valve to auto-
improve heating efficiency. When there is a problem with heating,
remove the clip and clean the filter. (see page 24)
