Wiring Diagram

Error Codes and DIP S/W Setting
Boiler Error Codes(Thermostat FND)
FND No.
01
Overheating
02
Low water level
03 Ignition failure
04
Flame sensor(Lower gas pressure)
Heating temp. sensor wire
05
disconnected
06
Short circuit of heating temp. sensor
09
Fan R.P.M. failure
10
Air pressure failure
No.
1
2
3
4
5
6
7
Model
131
No.
8 ON
9 OFF
10 OFF
Problems
Controller DIP S/W Setting
ON
Trial Operation
Forced MAX combustion
Forced MIN combustion
FE
LPG
Air Close Type
50Hz
161
OFF
ON
ON
60
FND No. Problems
11
Water level detection
12
Flame failure in combustion
Heating flow sensor failure
13
(for air close type model only)
14
Gas alarm (option)
15 MICOM failure
16
Mechanical over heating
17
DIP S/W setting error
18
OFF
Normal
Normal
Normal
FF
LNG
Air Open Type
60Hz
201 251
OFF ON
ON OFF
OFF ON
301
OFF
OFF
ON
