Gas Pipe Construction

Gas pipe construction must be done by gas dealer or gas pipe installation dealer.
1
The diameter of the gas pipes for this
unit is 15A(PT 1/2") or 20A(PT 3/4")
for each model.
See specifications in this manual(P63
∼66)
2
Gas pipes should be metal flexible
pipes that were approved by metal
pipe or gas part inspection testing.
When using LP gas, do not install the
fuse cork and a middle gas shut-off
valve must be installed.(installing fuse
cork can cause malfunctions.)
3
When using LP gas, use caution of
the following items :
LP gas governor should be house
hold low pressure governor that is
proper for gas usage indicated.
LP gas container should be 50kg
and use two or more containers.
(connect a twin valve to supply
gas from the two containers
simultaneously.)
※ In case the container capacity is
small, evaporation capacity is small
that it may cause gas waste and
normal operation may be hindered.
4
Boiler gas pipe should be directly
connected to the main pipe and do
not connect it along with other gas
appliances.
5
In the connection part, use a nut to
tighten the section that can be
attached and detached.
