Reinstalling the Desktop Stand
Replace the desktop stand by placing the upper desktop stand tab in
1
the voice terminal slot at the top of the voice terminal and make sure
the stand is oriented as in Figure 2.
Slowly rotate the desktop stand down until the tab at the bottom of
2
the desktop stand fits into the slot on the bottom part of the voice
terminal.
Replace the screw in the hole from which you removed it. See
3
Figure 2.
Connecting the 8510T to the System
Next, reconnect the cords of the 8510T voice terminal.
Plug in the line cord into the Line jack, and plug in the adjunct cord
1
into the Adjunct cord, if necessary.
Turn the voice terminal right side up, with the front facing you.
2
Decide whether you want the kickstand up, lifted from the desktop
3
stand, or whether you want the kickstand down, level with the
desktop stand. Check which of these kickstand adjustments allows
you the best viewing angle of the display.
Snap the free end of the line cord into the modular jack. Lift the
4
handset and listen for the dial tone.
