Removing the Voice Terminal Stand
Before you can remove and install an EPROM board, you must remove
the voice terminal desktop stand from the bottom of the voice terminal.
To remove the stand, follow these directions.
Place the voice terminal face down on a flat surface. The Bar Code
1
label on the bottom of the set should be toward you.
Remove the screw on the lower center of the stand. See Figure 2
2
for the location of the screw.
Remove the desktop stand attached to the base of the voice terminal
3
by tabs on the top and bottom of the stand. (See Figure 2).
Slowly rotate the bottom of the desktop stand up toward the top
of the voice terminal.
Then carefully lift the upper tab on the top of the stand out of the
upper tab slot.
