Socket Head Cap Screws (SHCS)
Thinner plate mounting component
Thicker plate mounting component
Bracket Installation
These brackets get mounted 90 degrees from each other on the OTA. Typically, they are attached on the
two sides that do not already have Losmandy dovetail installed (Figure 1).
Part Description
Rear mounting bracket (has no channel*, 2
pieces)
* The Paramount Taurus 400 brackets are the
same for the front and back rings.
Scope rail plate.
(40) 5/16-18 x 1-1/8-inch SHCS
(8) for Stainless Steel Rail/Mounting
¼-20 x 5/8-inch SHCS (6 pieces)
¼-20 x 1-1/8-inch Array Assembly Instructions
SHCS (6 pieces)
P a g e
| 6
