USER MANUAL
eiQ-9WMINV-V3
9,000 BTU
eiQ-12WMINV-V3
12,000 BTU
ENVIRONMENTALLY FRIENDLY
SMART WIFI CONTROLLED WALL MOUNTED
INVERTER SPLIT AIR CONDITIONER WITH HEAT PUMP
Thank you for choosing an electriQ Air Conditioner
Please read this manual before installing this innovative
Air Conditioner and keep it safe for future reference.
Advertisement
Table of Contents
Related Manuals for ElectrIQ eiQ-9WMINV-V3
Summary of Contents for ElectrIQ eiQ-9WMINV-V3
- Page 1 12,000 BTU ENVIRONMENTALLY FRIENDLY SMART WIFI CONTROLLED WALL MOUNTED INVERTER SPLIT AIR CONDITIONER WITH HEAT PUMP Thank you for choosing an electriQ Air Conditioner Please read this manual before installing this innovative Air Conditioner and keep it safe for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION GENERAL INSTRUCTIONS ENERGY SAVING AND UNIT PROTECTION TIPS PRODUCT OVERVIEW SYSTEM DIAGRAM HOW IT WORKS PARTS DIAGRAM OPERATING THE AIR CONDITIONER FUNCTIONS DISPLAY IMPORTANT INFORMATION CUSTOMISING YOUR AIR CONDITIONER OPTIONAL PANELS FOR THE INDOOR UNIT HOW TO CHANGE THE PANEL SETTING UP THE WIFI APP BEFORE YOU START CONNECTION METHODS AVAILABLE... -
Page 3: Safety Information
SAFETY INFORMATION • Before commencing work on the appliance the safety instructions from the user and installation manuals must be read and understood. During the work these instruction must be fully adhered to. If in doubt, please contact the manufacturer for assistance. •... -
Page 4: Energy Saving And Unit Protection Tips
SAFETY INFORMATION • The air conditioner contains about 320g (eiQ-9WMINV) or 400g (eiQ-12WMINV) of R290 refrigerant gas. • R290 is classed as flammable and as such naked flames and sources of ignition should be kept a safe distance from the unit. •... -
Page 5: Product Overview
PRODUCT OVERVIEW SYSTEM DIAGRAM Please note: The diagram is for illustrative purposes only, the actual product will differ... -
Page 6: How It Works
PRODUCT OVERVIEW HOW IT WORKS COOLING MODE The compressor (6) in the external unit compresses the refrigerant into a high-temperature, high-pressure gas. When this gas flows along the cooling fins of the condenser (7), heat is exuded and the gas condenses into a liquid, which is then led to the evaporator (1) in the indoor unit. -
Page 7: Parts Diagram
PRODUCT OVERVIEW PARTS DIAGRAMS INDOOR UNIT Description Front panel Air filter Optional filter LED Display Signal receiver Terminal block cover Ionizer generator (not applicable on all models) Deflectors Emergency button Indoor unit rating label Airflow direction louver OUTDOOR UNIT Description Air outlet grille Outdoor unit rating label Terminal block cover... -
Page 8: Operating The Air Conditioner
OPERATING THE AIR CONDITIONER FUNCTIONS COOL 1. Press the MODE button until the COOL indicator appears or press the COOL/COLD button. 2. Set the desired temperature using the TEMP and TEMP buttons. 3. Use the FAN button to adjust the fan speed. HEAT 1. - Page 9 OPERATING THE AIR CONDITIONER SHUTDOWN TIMER (WHILE THE AIR CONDITIONER IS ON) 1. Press the MODE button until the symbol appears for the operation you want. 2. Set the desired temperature. 3. Use the SPEED button to set the fan speed. 4.
-
Page 10: Display
OPERATING THE AIR CONDITIONER CHILD LOCK Press the LOCK button to turn the child lock on and off. When activated, the other buttons on the remote cannot be used until the lock has been turned back off. QUIET OPERATION Press the QUIET/MUTE button and the unit will operate at its quietest settings at low fan speed. This mode is only available in Cooling mode. -
Page 11: Important Information
OPERATING THE AIR CONDITIONER IMPORTANT INFORMATION HEATING MODE When the air conditioner is placed in heating mode, the indoor unit will appear to be inactive while it follows it’s preheat procedure to heat the evaporator coils. Once the coils have heated, the indoor fan will start to run. -
Page 12: Customising Your Air Conditioner
Your air conditioner is supplied with a white front panel but can be customised with the addition of optional front panels, allowing you to choose the look that best suits your room and preferences. These are available from the same retailer as the air conditioner under the following codes: MIRROR BLACK eiQ-Panel9KWM-MB eiQ-9WMINV-V3 SILVER eiQ-Panel9KWM-SV CHAMPAGNE eiQ-Panel9KWM-CH... -
Page 13: Setting Up The Wifi App
SETTING UP THE WIFI APP BEFORE YOU START • Ensure your router provides a standard 2.4ghz connection. • If your router is dual band ensure that both networks have different network names (SSID). The provider of your router / Internet service provider will be able to provide advice specific to your router. -
Page 14: Connection Methods Available
SETTING UP THE WIFI APP CONNECTION METHODS AVAILABLE FOR SETUP The air conditioner has two different setup modes, Quick Connection and AP (Access Point). The quick connection is a quick and simple way to set the unit up. The AP connection uses a direct local wifi connection between your phone and the air conditioner to upload the network details. -
Page 15: Registering The App
SETTING UP THE WIFI APP REGISTER THE APP 3. Enter your email address or 2. Read the Privacy policy and 1. Press on the register button press the Agree Button. phone number and press at the bottom of the screen. continue to register. -
Page 16: Setting Up Your Home Within The App
SETTING UP THE WIFI APP SETTING UP YOUR HOME WITHIN THE APP TUYA is designed so it can work with a large number of compatible smart devices within your home. It can also be set up to work with multiple devices within different houses. As such during the setup process, the app requires that different areas are created and named to allow easy management of all your devices. -
Page 17: Connecting Using Quick Connection
SETTING UP THE WIFI APP CONNECTING USING QUICK CONNECTION Before initiating the connection, make sure the unit is in standby mode, with the WIFI light flashing twice per second. If not follow the instructions for changing the connection mode. Also ensure your phone is connected to the WIFI network. -
Page 18: Connecting Using Ap Mode
SETTING UP THE WIFI APP CONNECTING USING AP MODE (ALTERNATIVE METHOD) Before initiating the connection, make sure the unit is in standby mode, with the WIFI light flashing once per second. If not follow the instructions for changing the WIFI connection mode. Also ensure your phone is connected to the WIFI network. -
Page 19: Using The Wifi App
USING THE WIFI APP Add Device: Add a device THE HOME SCREEN to the app, and go through the setup process. Voice Control: Use to give verbal instructions to the Your Device: Press app. to enter the device screen. Home: Return to this screen when within the Smart or profile tabs. -
Page 20: The Device Screen
USING THE WIFI APP DEVICE SCREEN The device screen is the main control screen for the air conditioner, providing access to the controls to amend the functions and settings Edit Name: Use to Back: Returns to the Home change the name of the air conditioner. -
Page 21: Smart Scenes
USING THE WIFI APP SMART SCENES Smart Scenes is a powerful tool providing the option to customise the operation of the air conditioner based both on conditions within the room and outside influences. This gives the user the option of specifying much more intelligent actions. - Page 22 USING THE WIFI APP AUTOMATION Automation allows an automatic action to be set up for the device. This can be triggered by the Time, indoor temperature, humidity of the room, weather conditions, and a range of other influences. 1. Press on the Smart Scene 2.
-
Page 23: Profile Tab
USING THE WIFI APP PROFILE TAB The profile tab gives you the option to edit both your detail, and use the added features of the unit. CHANGING THE NAME OF YOUR DEVICE When in any of the device screens further settings for the device can be accessed, by pressing on the three dots in the top right hand corner. -
Page 24: Troubleshooting
TECHNICAL SPECIFICATION TROUBLESHOOTING MALFUNCTION POSSIBLE CAUSE Power failure Damaged indoor/outdoor unit fan motor Faulty compressor thermomagnetic circuit breaker Faulty protective device or fuses The appliance does not Loose connections operate Self protection in adverse conditions Voltage higher / lower than the voltage range Active TIMER-ON function Damaged electronic control board Strange odour... -
Page 25: Fault Codes
Drive phase current overload fault Phase current sampling abnormal DECLARATION OF CONFORMITY Hereby, electriQ declares that this Portable air conditioner is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.electriQ.co.uk/content/declaration-of-conformity... -
Page 26: Technical Specification
TECHNICAL SPECIFICATION Model eiQ-9WMINV-V3 eiQ-12WMINV-V3 Rated voltage and frequency (Ph-V-Hz) 1Ph/220-240V~/50Hz 1Ph/220-240V~/50Hz Fuse Required Mode Cooling Heating Cooling Heating Rated capacity (W) 2600 2620 3500 3550 Power input (W) 1050 1020 Current input (A) SEER/SCOP(W/W) Nominal load (kW) Balance point temperature heating ( Min. -
Page 27: Warranty And Support
WARRANTY AND SUPPORT WARRANTY INFORMATION electriQ guarantee provides cover against material or manufacturing faults. This means that if your air conditioner develops a fault during the guarantee period, we will arrange for it to be repaired or replaced. Faults arising from a faulty installation are specifically excluded.
