Important Precautions
This unit has been engineered and manufactured to ensure your personal
safety, however improper use may result in potential e shock or fire hazards.
In order to allow the proper operation of all safeguards incorporated in this
display, observe the following basic rules for its installation, use, and
servicing.
On Safety
Use only the power cord supplied with the unit. In case you use another power
cord, make sure that it is certified by the applicable national standards if not being
provided by the supplier. If the power cable is faulty in any way, please contact the
manufacturer or the nearest authorized repair service provider for a replacement.
The power supply cord is used as the main disconnection device. Ensure that the
socket-outlet is easily accessible after installation.
Operate the display only from a power source indicated in the specifications of
this manual or listed on the display. If you are not sure what type of power supply
you have in your home, consult with your dealer.
Overloaded AC outlets and extension cords are dangerous. So are frayed power
cords and broken plugs. They may result in a shock or fire hazard. Call your service
technician for replacement.
Do not Open the Display.
There are no user serviceable components inside.
There are Dangerous High Voltages inside, even when the power is OFF.
Contact your dealer if the display is not operating properly.
To Avoid Personal Injury :
Do not place the display on a sloping shelf unless properly secured.
Use only a stand recommended by the manufacturer.
To Prevent Fire or Hazards:
Always turn the display OFF if you leave the room for more than a short period
of time. Never leave the display ON when leaving the house.
Keep children from dropping or pushing objects into the display's cabinet
openings. Some internal parts carry hazardous voltages.
Do not add accessories that have not been designed for this display.
During a lightning storm or when the display is to be left unattended for an
extended period of time, unplug it from the wall outlet.
A1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flatron L1810A and is the answer not in the manual?

Questions and answers

Summary of Contents for LG Flatron L1810A

  • Page 1 Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 2: Important Precautions

    Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 3: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Using the Computer Connect the signal cable. When attached, tighten the thumbscrews to secure the connection. Connect the plug from the AC adapter into the back of the monitor.
  • Page 4 Connecting the Display Side Jack Headphone/Earphone Input Automatically mutes the speaker volume when the headphones are plugged in. <Display>...
  • Page 5: Control Panel Functions

    Control Panel Functions Front Panel Controls L1810A VOL. SOURCE MENU AUTO/SELECT L1810T SOURCE MENU VOL. AUTO/SELECT Control Function Power Button Use this button to turn the display on or off. Power (DPMS) This Indicator lights up green when the display Indicator operates normally.
  • Page 6 Control Panel Functions Control Direct Access Function • Bring up Contrast and Brightness adjustment. • Use these buttons to go up and down the channel when the TV source is available. VOLUME: Use these buttons to decrease or increase the volume level. AUTO adjustment function When adjusting your display settings, always press the AUTO/SELECT button before entering the On Screen...
  • Page 7: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.
  • Page 8: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Using the computer Main menu Sub menu Reference BRIGHTNESS To adjust the brightness and BRIGHTNESS contrast of the screen CONTRAST CONTRAST PRESET 9300K...
  • Page 9 On Screen Display(OSD) Selection and Adjustment Using the VCR/DVD/TV/HDTV Main menu Sub menu Reference CHANNEL To select the TV channel settings CHANNEL and adjust the channel quality. SETUP ADD/DELL CH. AUTO CHANNEL SELECT FINE TUNE CONTRAST To improve the clarity and ADJUSTMENT stability of the screen BRIGHTNESS...
  • Page 10 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. To adjust the screen when using the computer To adjust the brightness and contrast of the screen OSD Adjust...
  • Page 11: To Adjust The Position Of The Screen

    On Screen Display(OSD) Selection and Adjustment To adjust the position of the screen OSD Adjust Description IMAGE POSITION Horizontal Position To move image left and right. R G B Vertical Position To move image up and down. HORIZONTAL VERTICAL To improve the clarity and stability of the screen OSD Adjust Description This function is suitable for analog signal...
  • Page 12 On Screen Display(OSD) Selection and Adjustment To customize the screen status for a user's operating environment OSD Adjust Description LANGUAGE To choose the language in which the SETUP control names are displayed. R G B LANGUAGE ENGLISH FULL IMAGE SIZE This function displays the image in its IMAGE SIZE OSD POSITION...
  • Page 13 On Screen Display(OSD) Selection and Adjustment To adjust the PIP of the screen OSD Adjust Description This PIP (Picture-in-Picture) function allows the image from the TV (HDTV), VCR or DVD to be displayed on a R G B sub-screen while you are using a computer. PIP ON/OFF PIP SOURCE V1(AV)
  • Page 14 On Screen Display(OSD) Selection and Adjustment To adjust the screen when using the VCR/DVD/TV To select TV channel settings and adjust the channel quality OSD Adjust Description To change the channel. CHANNEL CHANNEL SETUP ADD/DELL To add/delete the selected channels. CHANNEL ADD/DELL CH.
  • Page 15 On Screen Display(OSD) Selection and Adjustment To adjust the audio function OSD Adjust Description To decrease or increase volume level. VOLUME AUDIO VOLUME To decrease or increase bass level. BASS BASS TREBLE MUTE To decrease or increase treble level. TREBLE SOUND STEREO Used to select mute on (means sound off)
  • Page 16: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator Press the Power button.
  • Page 17: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is Press the AUTO/SELECT button to incorrect. automatically adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. Check Control Panel -->...
  • Page 18: Have You Installed The Display Driver

    Troubleshooting “IMAGE SIZE” function on OSD menu does not work. “IMAGE SIZE” function Check if the resolution is set as 1280x1024 or less on OSD menu does not than 512x360. work? The optimal resolution is 1280x1024 and the image is fully displayed on the monitor and is not converted as 1:1 image size.
  • Page 19: Audio Function

    Troubleshooting Audio function No sound. Check if the audio cable is correctly connected. Check the volume level. Sound is too high Adjust the TREBLE to an appropriate level. pitched or too low Adjust the BASS to an appropriate level. piched. Sound level is too low.
  • Page 20: Specifications

    Specifications 18.1 inches (45.97cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating 18.1 inches viewable 0.28mm pixel pitch Horizontal Freq. Analog:30 - 83kHz (Automatic) Sync Input Digital:30 - 71kHz (Automatic) Vertical Freq. 56 - 85Hz (Automatic) Input Form Separate TTL, Positive/Negative Composite TTL, Positive/Negative SOG (Sync On Green) Digital...
  • Page 21 Specifications Operating Conditions Environmental Temperature 10˚C to 35 ˚C Conditions Humidity 10 % to 80 % non-Condensing Storage Conditions Temperature -20˚C to 60 ˚C Humidity 5 % to 95 % non-Condensing Tilt/Swivel Stand Attached( O ), Detached ( Attached( ), Detached ( O ) Signal cable Wall-outlet type or PC-outlet type Power cord...
  • Page 22: Display Modes (Resolution)

    Specifications Display Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 640 x 350 31.468 720 x 400 31.469 640 x 480 37.500 VESA 640 x 480 VESA 43.269 640 x 480 VESA 37.879 800 x 600 VESA 46.875 800 x 600...
  • Page 23: Signal Connector Pin Assignment

    Specifications Signal Connector Pin Assignment & " DVI-D Connector Signal (DVI-D) Signal (DVI-D) T. M. D. S. Data2- Hot Plug Detect T. M. D. S. Data0- T. M. D. S. Data2+ T. M. D. S. Data0+ T. M. D. S. Data2/4 Shield T.
  • Page 24: Using The Remote Control

    : SMALL -> LARGE -> OFF PLAY VCR Buttons STOP P/STILL These buttons are available for LG VCR remote controls only. Refer to the Owner’s Manual for your VCR . LIGHT VIEW This function optimizes the brightness, contrast or color value LIGHT VIEW...
  • Page 25: Preparing The Remote Control

    Using the Remote Control Insert the batteries into the remote This section shows you how to use control to operate the monitor. the remote control. Preparing the Remote Operating with the Remote Control Control Open the battery cover. Point the remote control at the remote sensor and press the buttons.
  • Page 26: Connection Of External Equipment

    Connection of external equipment Connecting the VCR/DVD Connect the each audio/video output jack of the VCR/DVD to the corresponding input port as shown on the Display. If you connect the S-Video input port to external equipment, you can have an improved definition image.
  • Page 27: Watching Tv- Optional

    Connection of external equipment Watching TV- Optional Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. 1-1. As you see in the picture, connect the TV tuner pack to the monitor and use your hand or a screwdriver to fasten the thumbscrews.
  • Page 28 Connection of external equipment 1-2. Connect both HDTV cable (Y/Pb/Pr) and audio cable (Audio L/R) to the monitor jack and the Set-top box jack. Connect the plug from the AC adapter into the back of the monitor. Connect the power cord into a proper power outlet that is easily accessible and close to the display.
  • Page 29: Usb Connection

    Making use of USB (Universal Serial Bus) - Optional USB (Universal Serial Bus) is an innovation in connecting your different desktop peripherals conveniently to your computer. By using the USB, you will be able to connect your mouse, keyboard, and other peripherals to your display instead of having to connect them to your computer.
  • Page 30: Usb Specifications

    Making use of USB (Universal Serial Bus) - Optional USB Specifications Rev. 1.0 complied Self-powered hub USB standard 500mA for each (MAX) Downstream power supply 12 Mbps (full), 1.5 Mbps (low) Communication speed USB port 1 Upstream port 2 Downstream ports...
