User's Guide
L1750U
M
ake sure to read the Important Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for furture reference.
S
ee the label attached on the back cover and quote this information to your
dealer when you require service.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L1750U and is the answer not in the manual?

Questions and answers

Related Manuals for LG L1750U

Summary of Contents for LG L1750U

  • Page 1 User’s Guide L1750U ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the back cover and quote this information to your dealer when you require service.
  • Page 2 Announcement NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPER ATE THE EQUIPMENT. This equipment has been tested and found to comply with the limits for NOTE: a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential eletrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 4 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 5: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand base Place the monitor with its front facing downward on a cushion or soft cloth. Take out the cover and insert the power line.

  • Page 6: Removing The Stand Base

    Connecting the Display Removing the stand base Place the monitor with its front facing downward on a cushion or soft cloth. To remove the stand base, hold the bottom of the stand with one hand and release the screw as shown in the figure. Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off.

  • Page 7: Using The Computer

    Connecting the Display Using the Computer Place the monitor in a convenient, well-ventilated location near your computer. Connect the signal cable. When attached, tighten the thumbscrews to secure the connection . Connect the power cord into a proper power outlet that is easily accessible and close to the display.

  • Page 8: Control Panel Functions

    Control Panel Functions Front Panel Controls <L1750U> Control Function Use this button to enter or exit the On Screen Display. MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed.
  • Page 9 Control Panel Functions Control Function Use these buttons to select or adjust functions in the On Buttons Screen Display. Lightview hot key This feature lets you easily select the best desired image condition optimized to the environment NIGHT (ambient illumination, image types etc). •...

  • Page 10: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.

  • Page 11: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference To adjust the brightness, PICTURE BRIGHTNESS contrast and gamma of the CONTRAST screen GAMMA COLOR PRESET 6500K To customize the color of the screen...
  • Page 12 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 13 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS P I C T U R E To adjust the contrast of the screen. CONTRAST Set your own gamma value. : -50/0/50 GAMMA On the monitor, high gamma values display whitish images and low gamma...
  • Page 14 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description TRACKING To minimize any vertical bars or stripes CLOCK T R A C K I N G visible on the screen background.The horizontal screen size will also change. To adjust the focus of the display. This PHASE item allows you to remove any horizontal noise and clear or sharpen...

  • Page 15: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Check and see if the power cord is connected Is the power cord of the properly to the power outlet. display connected? Press the Power button. Is the power indicator light on? Adjust the brightness and the contrast.

  • Page 16: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Press the AUTO/SET button to automatically Display Position is adjust your display image to the ideal setting. incorrect. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. Check Control Panel -->...

  • Page 17: Have You Installed The Display Driver

    Troubleshooting Have you installed the display driver? Be sure to install the display driver from the Have you installed the display driver CD (or diskette) that comes with display driver? your display. Or, you can also download the driver from our web site: http://www.lge.com. Make sure to check if the video card supports Do you see an Plug&Play function.

  • Page 18: Specifications

    Specifications 17 inch Display 17 inches (43.2cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 17 inches viewable 0.26mm pixel pitch Sync Input Horizontal Freq. Analog:30 - 83kHz (Automatic) Vertical Freq. 56 - 75Hz (Automatic) Input Form Separate TTL, Positive/Negative SOG (Sync On Green) Signal Input 15 pin D-Sub Connector Video Input...

  • Page 19: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 640 x 350 31.468 720 x 400 31.469 640 x 480 VESA 37.500 640 x 480 VESA 37.879 800 x 600 VESA 46.875 800 x 600 49.725 832 x 624 VESA...
  • Page 20 How to Install the VESA Standard wall mounting This monitor meets VESA-compliant mounting interface pad specifications. VESA wall mounting Connected to another object (stand type and wall- mounted type. This monitor accepts a VESA- compliant mounting interface pad.- optional) For further information, refer to the VESA Wall Mounting Instruction Guide.
  • Page 21 Digitally yours...
