Summary of Contents for Nine Eagles Sky Climber 776B

  • Page 2 Climber 776B101101...
  • Page 3 Introduction Product Introduction NE R/C 776B is a good-sized glider designed by Nine Eagles Company latest, whose wing span is up to 2008mm. You only need to assemble the aerofoil and horizontal tail before starting to fly. The transmitter adopts standard 6CH computer intelligent device that makes the pilots to set any function according their own needs besides the function of mix-control of wing flap and aileron.
  • Page 4: Product Warning

    Packing details Identification Warning Product Warning...
  • Page 6: Battery Charging

    Battery charging 1. Introduction of charger 1.1 Charger input voltage: DC=10~15v I≥2500mA 1.2 The charger can charge the battery of 2S Li-Po or 3S Li-Po. (It is prohibited to connect both 2SLi-Po and 3S Li-Po to the charger at the same time.) 1.3 Charge current: ≤1500mA 1.4 battery charging voltage range: 4.15±0.05v 1.5 When a Li-Po battery voltage is under 2.7v,the charger will not continue to charge the Li-Po battery for it is...
  • Page 7: Installation Procedure

    Installation Procedure 1.1 Take the horizontal tail out of packing box. 1.2 Put the control surface downward and insert the fuselage from the left side. 1.3Connect it to the fuselage firmly, makes sure to install it to the right position and use screw to fix. 1.4Connect the adjustable connectors of push-pull wire to the control surface ,the hole site can be installed 2.1Take the left wing ,right wing and 1100mm connecting rod out.
  • Page 8: Install Battery

    2.5 Install another airfoil in this similar process and make sure that airfoil in both sides are inserted into fuselage completely and servo lead is connected correct. Install battery 1. Pull upward and open the aircraft window cover. 2. Turn on the transmitter and confirm the throttle lever is to the bottom before turning on the power,and then connect the speed controller to it.
  • Page 9 3. Switch on the power; you will hear "do re me” voice, indicating connection is normal. Control transmitter’s each channel at this time, the plane will work. Note: Close the aircraft window cover before flying and disconnect the power and remove the battery if not fly. 4.
  • Page 10 Introduction of wing flap function 1.First you should use computerized control equipment more than 6ch. 2.Connect the steering engine extended line (mongline) to 1ch and 6ch of transmitter respectively. 3.Conduct mix-control of 1ch and 6ch on the transmitter, 1ch is for aileron and 6ch is for wing flap. 4.The transmitter should be set on Toggle Switch, because wing flap can just in the middle or sway downward.
  • Page 11: After Flight

    attitude. Initially, the model will gently ascend, but within a few seconds it will reach enough speed to climb. Gently add “up” elevator to establish the climb. Once you have reached a safe flying speed at a comfortable altitude (approximately 50’[15m]), work the controls as necessary to establish a gentle turn away from the runway.
