Page 1
Line Striping System - For the application of road marking reflective materials - - For professional use only - Model 24F472 - Controller Only Model 24G632 - Controller, Cable, Remote Switch, and Bracket Important Safety Instructions Read all warnings and instructions in this manual.
Page 2
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
Component Identification and Function Component Identification and Function BEADS ON START SYSTEM SKIP DELAY SPACE BEAD TEST MENU MENU POWER RESET HOLD PROGRAMMABLE SKIPLINE CONTROL ti16359a Switch / Indicator Explanation A - F Menu Controls Provides menu specific commands as display on LCD screen. Provides skipline paint and cycle distance storage for instant change.
Installation Installation Operation Mount Programmable Skipline General Control To reduce the risk of serious injury, make sure that the Skipline Controller is turned OFF whenever you To reduce the risk of serious injury, mount the service any part of the RoadLazer system or leave Skipline Controller where it is easily visible and will the RoadLazer unattended.
Page 5
Operation Menus Information Readout (Startup/Main Menu) Measuring Counter: Resets every time HOLD/RESET is activated. Switch (J) must be in HOLD position & 6<67(0 '(/$< 21 See System Delay $GMXVW '(/$< ',67$1&( RU SUHVV Example, page 9. 6<67(0 $JDLQ WR UHWXUQ '(/$<...
Operation Distance Calibration 'LVWDQFH &DOLEUDWLRQ 'LVWDQFH &DOLEUDWLRQ 3XPS &DOLEUDWLRQ 6WDUW 6HW *XQ 'HOD\V & ([LW 6HWXS 0DUNHU /D\RXW 0RGH 'LDJQRVWLFV ti16376a 7UDYHO 'LVWDQFH The Distance Calibration Menu is used to calibrate the system against a measured distance (see Distance 2. Press at the beginning of the measured Calibration Procedure, page 9).
Page 7
Operation Setup Distance Units Distance Calibration GALLONS or LITERS Pump Calibration Set Gun Delays Display SPACE or CYCLE Setup Adjust Display Contrast Marker Layout Mode Bead Gun Enable/Disable Diagnostics System Type ti16378b Distance Units Changing units will reset to factory settings English ft/in/mph Metric...
Operation Distance Calibration Procedure 7. Press button. NOTE: Although the RoadLazer is calibrated prior to 8. The system is now calibrated. shipping, the sensor will need to be recalibrated periodi- cally due to wheel wear, and also whenever the gun-arm wheel is replaced.
Page 10
Operation Example: Painting Two Solid Lines with the One-Operator System ™ Delay 1. Turn on System Delay. 2. Set guns 1 and 2 in the solid position and the RESET/HOLD switch in the hold position. Reset Hold ti16401a 3. Align the mechanical reference point with the begin- ning of the area to be painted (A).
Page 11
Operation Skipline Applications with ™ One-Operator System Delay 1. Turn on System Delay. 2. Load the cycle and paint length of the skipline to be painted using the First Menu. 3. Align the mechanical pointer with point A. 4. Set gun 1 to Skip, and toggle the HOLD/RELEASE switch to center.
Troubleshooting Troubleshooting Problem Cause Solution Control will not turn on. 12 VDC power supply low, or discon- Connect the I/O cable. nected. Charge the RoadLazer battery. Check the battery connections. Guns will not spray. Various causes. Toggle RESET on the controller. Check the paint supply.
Page 13
Troubleshooting Control Cable Diagram for RoadPak ** All ground pins MUST be connected to ground ++ Input for pull-up/PNP/Sourcing Sensor System Contact Description Action 12 VDC Supply Voltage Leave Open - Do Not Connect Leave Open - Do Not Connect Sensor, pump (1) Input Sensor, pump (2)
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
