- Page 1 Instruction Sheet For: FP-XMFT & FP-XMFTB For more information, please contact us at: 345 Log Canoe Circle, Stevensville, Maryland 21666 Toll Free: 877.281.2169 Phone: 410.643.6390 Fax: 410.643.6615 www.videomount.com...
- Page 3 Step 1 Before starting, lay out all parts to your mount and match them to the parts list provided. Verify that you have all your parts before attempt- ing to assemble the mount. Step 2 Assemble the wall plate by attaching the two horizontal wall plates using the vertical supports and short M4 screws .
- Page 4 Step 5 Adjust the tilt tension by tightening the socket head screws with so they are fairly tight. Note: You may have the M5 Allen Key to adjust the tilt tension once the flat screen is on the wall so do not tighten as hard as you can because it will make further adjustment on the wall much more difficult.
