Sterling Series
Sofa Table
Model No. STST
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
P/N
STST Rev 1 05/06/15
TM
www.mayline.com
Spare
Name
Part
Qty.
Qty
HB
A
4
REALS612
Mounting Plate
HB
B
16
1
REALS603
M6x15mm
HB
4
C
REALS425
Leveler
HB
D
34 1
REALS003
Cam Post
HB
34 1
E
REALS001
Cam Lock
HB
34 1
F
REALS517**
Cam Sticker
Items with HB are in hardware box.
Spare
Name
Part
Qty.
Qty
HB
G
4
REALS607
Ø32mm Base Stand-off
HB
H
2
REALS613
Ø32mm Base Stand-off
HB
I
4
1
REALS206
M6x15mm
HB
J
1
REALBY028
Wrench 4mm
STSTHB
1
Advertisement
Table of Contents
Related Manuals for Mayline Sterling Series STST
Summary of Contents for Mayline Sterling Series STST
- Page 1 REALS425 M6x15mm Leveler 34 1 REALBY028 REALS003 Wrench 4mm Cam Post 34 1 REALS001 STSTHB Cam Lock 34 1 REALS517** Cam Sticker ASSEMBLY INSTRUCTIONS CALL 1-800-822-8037 FOR ASSISTANCE Items with HB are in hardware box. STST Rev 1 05/06/15 www.mayline.com...
- Page 2 Part Qty. Name Part Qty. improper assembly or installation. Mayline and/or its distributor are not responsible for failure resulting from improper assembly or installation of this product. Moreover, all warranties are void for failure to follow these assembly instructions. STCT**P Insert Cam Post (D) into Leg (P).
- Page 3 Insert Cam Post (D) into Leg (P). Install Cam (E) Modesty Panel (L&M). Install Base Stand-off (G) into threaded inserts in upperside of Leg (P). Attach Modesty Panel (L&M) to assembled sofa table Base by turning Install Mounting Plate(A) into Base Stand-off (G) by using Screws (I). Cams (E).
- Page 4 Install the Mounting Plate(A) to the underside of Top (K) using Screws (B) and Wrench (J).Install Cams (E) modesty Panel (M).Apply Cam Stickers (F) to Cams (E) of Modesty Panel (M).
