Sterling Series
Credenza 72"/66"
Model No. STCT72/66
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
P/N
STCT72/66 Rev 2 05/16/16
TM
www.mayline.com
PARTS LIST
Spare
Name
Part
Qty.
Qty
HB
A
2
REALS604
Round Clamp
HB
B
2
1
REALS605
M6x20mm
HB
C
1
REALBY028
Wrench
STCT72HB
Items with HB are in hardware box.
**Denotes Color Code
~~ Denotes Size-72/66
Spare
Name
Part
Qty.
Qty
HB
D
1
REALS100
Grommet
E
1
STCT~~**
Top
F
1
STCTF**
Modesty Panel
1
