Sterling Series
Sterling Series
Bookcase, 2 Shelf
Model No. STEB2C
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
P/N STEB2C Rev 3 12/05/16
TM
www.mayline.com
PARTS LIST
Spare
Name
Part
Qty.
Qty
HB
A
8
1
REALS004
Wood Dowel
HB
B
8
1
REALS001
Cam
HB
8
1
C
REALS002
Cam Post
HB
8
1
D
REALS102**
Cam Sticker
HB
4
E
REALS425
Leveler
HB
4
F
REALS009
Shelf Support
Items with HB are in hardware box.
**Denotes Color Code
Spare
Name
Part
Qty.
Qty
HB
G
18
1
REALS146
Ø3x19mm
HB
4
H
REALS607
Ø32*50mm Base Stand-off
HB
4
1
I
REALS637
M6 x 35mm
HB
4
1
J
REALS638
M6 Flange Nut
HB
1
K
REALS639
10mm Wrench
STEB2CHB
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mayline Sterling Series
Summary of Contents for Mayline Sterling Series
-
Page 1: Parts List
PARTS LIST Spare Spare Name Part Qty. Name Part Qty. Sterling Series Sterling Series Bookcase, 2 Shelf Model No. STEB2C REALS004 REALS146 Wood Dowel Ø3x19mm REALS001 REALS607 Ø32*50mm Base Stand-off REALS002 REALS637 M6 x 35mm Cam Post REALS102** REALS638 M6 Flange Nut... - Page 2 Part Qty. instructions are provided to avoid problems that may occur from improper assembly or installation. Mayline and/or its distributor are not responsible for failure resulting from improper assembly or installation of this product. Moreover, all warranties are void for failure to follow these assembly instructions.
- Page 3 Attach the Back Panel (P) to the Top (L), Side Panels (M & N) and the Insert Wood Dowels (A) and Cam (B) into Side Panels (M & N). Install Bottom Panel (O) by using Screws (G). Cam Posts (C) in Top (L) and Bottom panel (O). Attach Top (L) and Bottom panel (O) to assembled cabinet by turning Cams (B).
- Page 4 Insert Shelf Supports (F) into the Side Panels (M & N) at the desired height. Put the Shelf Panel (Q) on the Shelf Supports (F).
