54" 3-in-1 Console (XLO2254CR-NV)
This item is designed to be 3-in-1 configuration. Please choose which of the 3 options suits your
needs. DO NOT discard any of the hardware or parts that you will not use on your set option, this
will give you the opportunity to use this TV Console for different configurations in case you decide
to upgrade your TV set in the future.
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if you are missing parts, do not return this
item to the Retailer Store. Please call our toll free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-866-942-5362
ONLINE: www.whalenfurniture.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
VAS Furniture Mfg. Inc.
8:30 a.m. - 4:30 p.m. PST, Monday - Friday
Video Instruction Guides
Go to http://whalen.showuhow.com to view step-by-step instructional
videos for assembling and installing your product. Enter the following
product number on the ShowUhow homepage.
XLO2254CR-NV
LOT NUMBER:
DATE PURCHASED:
Option 1:
With Swinging Floater
EMAIL: parts@whalenfurniture.com
Page 1
/
/
Factory No. 33-10944
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VAS XLO2254CR-NV
Summary of Contents for VAS XLO2254CR-NV
- Page 1 LOT NUMBER: DATE PURCHASED: 54” 3-in-1 Console (XLO2254CR-NV) This item is designed to be 3-in-1 configuration. Please choose which of the 3 options suits your needs. DO NOT discard any of the hardware or parts that you will not use on your set option, this will give you the opportunity to use this TV Console for different configurations in case you decide to upgrade your TV set in the future.
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: VAS Furniture CATALOG: 54” 3-in-1 Console (XLO2254CR-NV) DATE OF MANUFACTURE: November, 2010 MADE IN CHINA FITS UP TO MOST 60”...
- Page 3 Model # XLO2254CR-NV Parts and Hardware List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A-Top Shelf Frame (1) B- Middle Shelf Frame (1) C- Bottom Shelf Frame (1) D- Long Spine (1)
- Page 4 Model # XLO2254CR-NV Parts and Hardware List (2) - 3/4” Bolt (3) - 1 1/4” Bolt (1) - Suction Cup (16+1 extra) (28+1 extra) (7+1 extra) (4) –Hex Nut (6) –Flat Washer (5) - Lock Washer (4+1 extra) (31+1 extra) (35+1 extra) (8) - 2 1/2”...
- Page 5 Model # XLO2254CR-NV Assembly Instructions Note: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make it easier during assembly of unit. 1. Choose the option suits your needs. Locate Long Spine (D) or Short Spine (D1) and set back face down on a scratch free surface as shown in detail #1.
- Page 6 Model # XLO2254CR-NV Assembly Instructions 4. Stand the unit upright. 5. Align and attach Left Leg (E) to the Top and Middle Shelf Frame (A & B) by inserting 3/4” Bolts (2) with Washers (5 & 6) through the end bracket holes into the threaded inserts on the Leg.
- Page 7 Model # XLO2254CR-NV Assembly Instructions 8. Go back and tighten all bolts with Allen Wrench provided. 9. In case of uneven floor, Floor Levelers are provided at the bottom of both Legs (E & F). Simply tilt the unit back and raise or lower floor leveler by hand to correct tilting as shown in detail #3.
- Page 8 Model # XLO2254CR-NV Assembly Instructions for Table-top 10. Attach 2 Cable Controls (N) onto the backside of Spine (D1) with the 3/4” Bolts (2). Tighten the bolts with Allen Wrench provided. See detail #4. 11. The Cable Controls (N) enable you to shorten, separate and route cables and cords. Using...
- Page 9 Model # XLO2254CR-NV Assembly Instructions for Table-top 12. Put Suction Cups (1) firmly into the top holes and metal tabs on Middle Shelf Frame (B) and Bottom Shelf Frame (C) as shown in detail #5. 13. Screw 8 Glass Risers (10) all the way into the top holes of Top Shelf Frame (A) and Left &...
- Page 10 Model # XLO2254CR-NV Assembly Instructions for Table-top 15. Position the assembled Table-top in your desired location against the wall. Now follow the instructions printed on the plastic bag in order to mount the Tipping Restraint Hardware Kit to the Spine properly. As shown in detail #6.
- Page 11 Model # XLO2254CR-NV A s s e m b l y I n s t r u c t i o n s f o r O p t i o n 1 : C o n s o l e w i t h S w i n g i n g F l o a t e r attach Swiveling Bracket (J) to the top of Long Spine (D) using six 3/4”...
- Page 12 Model # XLO2254CR-NV Assembly Instructions 18. Hold the flat side of XYZ Mounting Frame (K) onto the Swiveling Bracket (J) ensuring the hook on the side of Mounting Frame is bottom. Align and attach by threading four 3/4” Bolts (2) with Flat Washers (6) through the metal plate on XYZ Mounting Frame and the Swiveling Bracket, at the other side of Swiveling Bracket place the other Flat Washers (6) and Lock Washers (5), and then secure with Hex Nuts (4).
- Page 13 Model # XLO2254CR-NV Mounting Monitor Bracket to a television with a flat back Note: For televisions with a curved back or recessed back proceed directly to step #22. 19. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV.
- Page 14 Model # XLO2254CR-NV Mounting Monitor Bracket to a television with a curved / recess back 22. Determine the correct diameter of the bolt your TV requires by hand threading them into the threaded insert on the back of the TV. If you encounter any resistance, stop immediately. If you are unable to find the correct bolt consult a local hardware store.
- Page 15 Model # XLO2254CR-NV Assembly Instructions MAKE SURE ALL BOLTS ARE TIGHT AND SPINE IS AT A 90 DEGREE ANGLE AND USING A QUALITY LEVEL TO VERIFY THE MOUNTING FRAME IS LEVEL PRIOR TO INSTALLATION OF TV. 25. Once the Monitor Brackets (L) are attached onto the back of television, ask for assistance to lift the television up to the XYZ Mounting Frame (K).
- Page 16 Model # XLO2254CR-NV Assembly Instructions Repeat steps 10 thru 14 to install the Cable Controls (N) and attach the Top Glass (G) and Glass Shelves (H & I) in place. 28. Carefully move the console and position in your desired location against the wall. Now follow the instructions printed on the plastic bag in order to mount the Tipping Restraint Hardware Kit to the Spine properly.
- Page 17 Model # XLO2254CR-NV Assembly Instructions for Universal Wall Mount Installing XYZ Mounting Frame onto WOODEN WALL 30. The XYZ Mounting Frame (K) must be mounted to two Wood Studs at least 12” apart, using a high quality Stud Finder to locate the two adjacent studs. After you have located the studs, verify with a nail for added security.
- Page 18 Model # XLO2254CR-NV Assembly Instruction for installing XYZ Mounting Frame onto BRICK, SOLID CONCRETE OR CONCRETE BLOCK 33. Use the XYZ Mounting Frame (K) as a template, mark six holes location on the wall, three in the top row and three in the bottom row of slots. Make sure that the holes are level and there is at least 6”...
- Page 19 Model # XLO2254CR-NV Assembly Instructions 36. Once the Monitor Brackets (L) are attached onto the back of television, ask for assistance to lift the television up to the XYZ Mounting Frame (K). Place the hooks on Monitor Brackets over the Mounting Frame then lower them onto the bars of Mounting Frame. Proceed to center the television.
-
Page 20: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every VAS Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
