Installation and Assembly - Multi-Channel Speaker
IMPORTANT! Read entire instruction sheet before you start installation and assembly.
NOTE:
For use with FS-3200 C and FS-3200 LR speakers only
Parts List
Description
A cross support
B side extension
C speaker bracket
D extension bracket bottom
E M5 x 10 mm phillips screw
F #10 SAE flat washer
G M5 x 20 mm phillips screw
H adhesive velcro
Note: some parts may not appear exactly as illustrated.
A
B
E
Visit the Peerless Web Site at www.peerlessmounts.com
Accessory
MSA-301
Qty.
Part #
1
087-1051
2
087-1054
3
087-1057
1
087-1050
24
520-1233
12
540-9400
12
510-1208
3
600-1018
F
MSA-301S
Part #
087-4051
087-4054
087-4057
087-4050
520-1233
540-9400
510-1208
600-1018
C
G
1 of 3
For customer care call 1-800-865-2112 or 708-865-8870.
Models: MSA-301,
MSA-301S
MAXIMUM LOAD CAPACITY:
50 lb (22.68 kg)
D
H
ISSUED: 02-09-07 SHEET #: 087-9014-1
Advertisement
Table of Contents
Related Manuals for PEERLESS MSA-301
Summary of Contents for PEERLESS MSA-301
- Page 1 G M5 x 20 mm phillips screw 510-1208 510-1208 H adhesive velcro 600-1018 600-1018 Note: some parts may not appear exactly as illustrated. 1 of 3 ISSUED: 02-09-07 SHEET #: 087-9014-1 Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
- Page 2 10mm screws and flat washers (E, F). Do not fully tighten screws to allow for position adjustments when attaching center speaker. 2 of 3 ISSUED: 02-09-07 SHEET #: 087-9014-1 Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
- Page 3 ISSUED: 02-09-07 SHEET #: 087-9014-1 Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870. © 2007, Peerless Industries, Inc. All rights reserved. All other brand and product names are trademarks or registered trademarks of their respective owners.
