GL3000
8 CHANNEL MONO MODULE
4 MONO + 4 STEREO MODULE
PART NO:
PART NO:
I N T R O D U C T I O N
The GL3000-8M and GL3000-4SM are an 8 channel mono input module and a 4 mono + 4 stereo input
module respectively for fitting to the GL3000 series of consoles. These expander modules allow a
GL3000 console to be expanded up to a maximum of 40 channels.
Please read the following instructions carefully before attempting to fit the module.
1
Check contents of pack to ensure all parts have been supplied.
A
PART NO. AB0336
QUANTITY 2
CATCHPLATE
P
PART NO. AB0062
QUANTITY 4
SCREW 6ABX3/8
PART NO.s AK2365 AK2398 AK2542
K
QUANTITY 1
IDENT STRIP
N
PART NO. AA2404
QUANTITY 1
BASE BRACKET
ALLEN & HEATH
EXPANDER
GL3000-8M
GL3000-4SM
FITTING INSTRUCTIONS
B
PART NO. AB0335
QUANTITY 2
AJUSTABLE FASTENER
G
PART NO. AB0325
QUANTITY 4
STUD M6X38.5
PART NO.s 002-103 or 002-104
QUANTITY 1
8 CHANNEL MONO MODULE
4 MONO + 4 STEREO MODULE
C
PART NO. AB2421
QUANTITY 1
SCREW M6X8 SKT HEX
E
PART NO. AB2084
QUANTITY 10
SCREW 6BX5/16
H
PART NO. AB2406
QUANTITY 1
STUD SLOTTED
L
PART NO. AB2085
QUANTITY 6
SREW 8BX3/8 CSK
AP2376 ISS 1
D
PART NO. AB2304
QUANTITY 3
SCREW M3X8 HEX
F
PART NO. AB0271
QUANTITY 4
SCREW M4X10
J
PART NO. AB0102
QUANTITY 3
NUT LOCK M3
M
PART NO. AB0188
QUANTITY 4
NUT LOCK M4
THESE
FITTING
INSTRUCTIONS
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ALLEN & HEATH GL3000 Series
Summary of Contents for ALLEN & HEATH GL3000 Series
- Page 1 The GL3000-8M and GL3000-4SM are an 8 channel mono input module and a 4 mono + 4 stereo input module respectively for fitting to the GL3000 series of consoles. These expander modules allow a GL3000 console to be expanded up to a maximum of 40 channels.
- Page 2 EXPANDER POSITIONING The Expander module must be fitted in the position shown in the diagrams below. GL3000-816 Expander E X P A N D E R 1 - 8 9 - 16 MASTER GL3000-824S Expander stereo 17 - 24 E X P A N D E R 1 - 8 9 - 16 MASTER...
-
Page 3: Installation
INSTALLATION Only technically competent personel should attempt to fit the expander module Disconnect GL3000 from Power Supply Unit and cables before fitting the module Ensure you have a good work surface and clear area before starting work. Remove the optional Meterbridge if fitted. - Page 4 Attach the adjustable fastener and catchplate to the front extrusion of the console and expander using screws and nuts . The mounting holes are located under the front armrest of each unit and are pre-drilled for the adjustable fastener and catchplate. Attach adjustable fastener 'A' and catchplate 'B' Attach the second adjustable fastener and catchplate...
- Page 5 Screw the slotted stud into the top rear extrusion of the console. Slide the expander module Ž • onto the 5 studs and close the 2 adjustable fasteners over the catchplates , see & The fasteners can be adjusted to ensure a good join. Screw in the locking screw into the pre- 'H', tapped hole.
-
Page 6: Testing The Console
NUMBER STRIP POSITIONING A complete set of number strips is supplied with the Expander kit. The existing number strip on the console can be replaced with the new set. The diagrams below show the combination of strips to be fitted to the expanded consoles. GL3000-816 Expander E X P A N D E R...
