Quick Start EVK-W262U
USB
Reset
Connector
button
(J2)
(SW1)
UBX-15016340 - R02
Restore
RGB
button
LED
(LD5)
(SW2)
UART
ODIN-W2
indication
multiradio
LEDs
module
(LD3, LD4,
(M1)
LD1, LD2)
1. Setup
Download the EVK-W262U software
(and documentation) from www.u-blox.
com/evk-downloads. Click on "Resources
to download" and install the software.
See notes on back of the card.
1. Insert the EVK-W262U kit into a
USB port on your computer.
2. Verify that the FTDI driver is
installed successfully. If necessary,
download the drivers for the FT231X
chipset from www.ftdichip.com.
3. Download the latest firmware to the
ODIN-W2 module using s-center
evaluation software.
Advertisement
Table of Contents
Related Manuals for Ublox EVK-W262U
Summary of Contents for Ublox EVK-W262U
- Page 1 Click on “Resources to download” and install the software. See notes on back of the card. 1. Insert the EVK-W262U kit into a USB port on your computer. 2. Verify that the FTDI driver is installed successfully. If necessary, download the drivers for the FT231X chipset from www.ftdichip.com.
- Page 2 2. Installation 3. Troubleshooting To download the EVK-W262U software To restore to factory default settings: package and run the installation: Toggle the Reset button (SW1) while • An Internet connection is required. holding the Restore button (SW2) until Supported Windows operating the RGB LED (LD5) turns orange and systems: Vista, 7 and 8.
