ETI PI-800 Instruction Manual page 12

Electrical Test Instruments PI-800 and PI-1600
Section I - General Information and Specifications
==============================================================================
PI-1600
INPUT SUPPLY:
240 VAC + 10%, -15%, SINGLE PHASE
60 HZ (50 Hz at 10% lower maximum line voltages)
8.8 KVA (Continuous) at 8.0 KVA output (90% efficiency)
(Note: Specifications include required PI-800 unit)
PI-1600 OUTPUT CURRENT & OVERLOAD CAPABILITIES:
5.0V (Par) 10 V (Ser)
1600 A 800 A
2250 A 1125 A
3200 A 1600 A
4800 A 2400 A
6400 A 3200 A
8000 A 4000 A
11200 A 5600 A
16000 A 8000 A
25000 A ** 12500 A **
**Maximum output current possible into short circuit with very low source impedance
Additional Equipment Required
Requires a complete PI-800 (including MAC-21) for operation
See separate data sheet for specifications
DIMENSIONS AND NET WEIGHT (for PI-Aux Booster)
Height: 11.5 in. (292 mm)
Width: 21.5 in. (546 mm)
Depth: 18.5 in. (470 mm), 22.5 in (572 mm) with lids
Weight:
STANDARD ACCESSORIES
Connection bar
800-amp output connectors
Series connection bar
Technical manual
Stab adaptor plates
Standard universal breaker stabs (1/2" horiz and vert)
Standard universal breaker stabs (3/4" horiz and vert)
OPTIONAL ACCESSORIES
Autotransformer 208/480 VAC model AT-10 (provides use on standard 208/480VAC)
==============================================================================
Copyright(C) 1994-2003
Ovld Duty Max ON Time
*
1x 100% CONTINUOUS
1.4x 50% 15 Minutes
2x 25% 5 Minutes
3x 10% 2.5 Minutes
4x 6% 75 Seconds
5x 4% 4 Seconds
7x 2% 2 Seconds
10x 1% 0.6 Second
15x 0.5% 0.1 Seconds
110 lb. (50 kg)
Electrical Test Instruments, LLC.
Page I-8
Min OFF Max Inp Curr
Time (@240V)
N/A 37
15 Minutes 52
15 Minutes 74
20 Minutes 111
20 Minutes 148
2 Minutes 185
2 Minutes 259
1 Minute 370
1 Minute 555 **
2 each
4 each
1 each
1 copy
4 each
2 each
2 each
All Rights Reserved
