Electrical Test Instruments PI-800 and PI-1600
Section I - General Information and Specifications
==============================================================================
PI800
INPUT SUPPLY:
120 or 240 VAC + 10%, -15% (Switch Selectable), SINGLE PHASE
60 HZ (50 Hz at 10% lower maximum line voltages)
3.8 KVA (Continuous) at 3.4 KVA output (90% efficiency)
PI-800 OUTPUT CURRENT & OVERLOAD CAPABILITIES:
4.2V (S/P) 8.4 V
(Ser)
800 A 400 A
1120 A 560 A
1600 A 800 A
2400 A 1200 A
3200 A 1600 A
4000 A 2000 A
5600 A * 2800 A *
8000 A * 4000 A *
12500 A ** 6250 A **
*Available with 240 VAC input only; Max ON Times may be less at 120 VAC
**Maximum output current possible into short circuit with very low source impedance
DIMENSIONS AND NET WEIGHT (Not including MAC-21)
Height:
Width:
Depth:
Weight:
STANDARD ACCESSORIES
Input power plugs only
Series/Parallel and Output buswork
Contacts leads
Technical manual
==============================================================================
Copyright(C) 1994-2003
Ovld Duty Max ON Time
*
1x 100% CONTINUOUS
1.4x 50% 15 Minutes
2x 25% 5 Minutes
3x 10% 2.5 Minutes
4x 6% 75 Seconds
5x 4% 4 Seconds
7x 2% 2 Seconds
10x 1% 0.6 Second
15x 0.5% 0.1 Seconds
11.5 in. (292 mm)
21.5 in. (546 mm)
18.5 in. (470 mm), 22.5 in (572 mm) with lids
125 lb. (57 kg)
Electrical Test Instruments, LLC.
Page I-7
Min OFF Max Inp Curr
Time (@240/120)
N/A 16 / 32
15 Minutes 23 / 46
15 Minutes 32 / 64
20 Minutes 48 / 96
20 Minutes 64 / 128
2 Minutes 80 / 160
2 Minutes 112 *
1 Minute 160 *
1 Minute 240 *
2 each
1 set
1 pair
1 copy
