Keysight MXA 902 Series Installation Note

Keysight MXA 902 Series Installation Note

Signal analyzer option hlb, 40 mhz to 85 mhz analysis bandwidth upgrade serial prefix my/sg/us5233
Hide thumbs

Advertisement

Quick Links

Download this manual
Keysight MXA Signal Analyzer
Option HLB, 40 MHz to 85 MHz Analysis
Bandwidth Upgrade
Serial Prefix < MY/SG/US5233
Notice: This document contains references to Agilent.
Please note that Agilent's Test and Measurement busi-
ness has become Keysight Technologies. For more in-
formation, go to www.keysight.com.
Installation Note
Part Number N9020-90239
Printed in USA August 2014

Advertisement

loading

Related Manuals for Keysight MXA 902 Series

Summary of Contents for Keysight MXA 902 Series

  • Page 1 Bandwidth Upgrade Serial Prefix < MY/SG/US5233 Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement busi- ness has become Keysight Technologies. For more in- formation, go to www.keysight.com. Installation Note Part Number N9020-90239 Printed in USA August 2014...
  • Page 2 Agilent Technologies shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. © Copyright 2013 - 2014 Keysight Technologies, Inc.
  • Page 3 Option HLB, 40 MHz to 85 MHz Analysis Bandwidth Upgrade Serial Prefix < MY/SG/US5233 Option HLB, 40 MHz to 85 MHz Analysis Bandwidth Upgrade Serial Prefix < MY/SG/US5233 Products Affected: N9020A, MXA Signal Analyzer < MY52330000 Serial Numbers: < SG52330000 <...
  • Page 4 Option HLB, 40 MHz to 85 MHz Analysis Bandwidth Upgrade Serial Prefix < MY/SG/US5233 Software and test equipment is required for making adjustments and for performance verification testing. Information on how to obtain this software can be found at: www.agilent.com/find/calibrationsoftware NOTE Instrument software revision A.13.15 or later is required to install this upgrade.
  • Page 5 Option HLB, 40 MHz to 85 MHz Analysis Bandwidth Upgrade Serial Prefix < MY/SG/US5233 Installation Kit Parts List Quantity Description Agilent Part Number Power Supply, AC/DC Switching 350W 12-Output 0950-5012 A3 40 MHz Digital IF Assembly N9020-60016 A25 Wideband Analog IF N9020-60044 A26 Wideband Digital IF N9020-60257...
  • Page 6 Option HLB, 40 MHz to 85 MHz Analysis Bandwidth Upgrade Serial Prefix < MY/SG/US5233 Tools Required • T-10 TORX Driver • T-20 TORX Driver • 5/16-inch torque wrench • 9/16-inch nut driver • 1/4-inch socket on 4-pound torque wrench • Scissors or knife •...

  • Page 7: Installation Procedure

    Installation Procedure Installation Procedure Analyzer Information 1. Connect a power cord to the analyzer and turn on the analyzer. 2. After the analyzer has completed turning on, press System Show System . Make note of the following information from the Show System screen: Product Number ________________ Serial Number ________________ Instrument S/W Revision ________________...

  • Page 8: Update Instrument Software

    Installation Procedure Update Instrument Software Updating the instrument software and installing the necessary licenses before installing the new hardware will help ensure that the hardware installation was successful. NOTE The minimum instrument software version is A.13.15. Go to the following website and determine whether or not the analyzer has the latest instrument software already installed: http://www.agilent.com/find/xseries_software If the analyzer does not have the latest instrument software already installed, download and install the...
  • Page 9 Installation Procedure Licensing the New Options NOTE If N9020AK-BU4, Analysis Bandwidth Upgrade, 85 MHz to 125 MHz, N9020AK-BU5, Analysis Bandwidth Upgrade, 85 MHz to 160 MHz, or N9020AK-B40, Analysis Bandwidth Upgrade, 40 MHz will also be installed, the licenses provided by these kits should be installed at this time. 1.
  • Page 10 Installation Procedure 7. The signal analyzer will automatically consume the License File. (This may take a few minutes) When the License File is consumed the Agilent License Manager will display a “Successful License Installation” message as shown in Figure 2. Since the license file contains multiple licenses, multiple “Successful License Installation”...

  • Page 11: Analyzer Disassembly

    Installation Procedure Analyzer Disassembly CAUTION If the instrument is placed on its face during any of the following procedures, be sure to use a soft surface or soft cloth to avoid damage to the front panel, keys, or input connector. NOTE If the analyzer has Option PRC, Portable Configuration, refer to the “Portable...
  • Page 12 Installation Procedure Figure 3 Standard Instrument Outer Case Removal 5. Proceed to the Front Frame Assembly Removal section to remove the front frame. Installation Note N9020-90239...
  • Page 13 Installation Procedure Portable Instrument (Option PRC) NOTE Make sure any adapters on the front panel are removed. 1. Disconnect the instrument from ac power. 2. Refer to Figure 4. Using the T-20 driver, remove the four screws (two on each side) (1) that hold the bail handle (2) to the front frame.
  • Page 14 Installation Procedure 4. Refer to Figure 5. Using the T-20 driver, remove the four screws including washers (1) that hold the rear bumpers (2) in place. 5. Pull the instrument cover (3) off towards the rear of the instrument. Figure 5 Option PRC Instrument Outer Case Removal Installation Note N9020-90239...
  • Page 15 Installation Procedure Front Frame Assembly Removal 1. Refer to Figure 6. Using the T-10 driver, remove the eight screws (1), four on each side, to detach the front frame from the chassis. Figure 6 Front Frame Removal Installation Note N9020-90239...
  • Page 16 Installation Procedure 2. Refer to Figure 7. Pull the front frame carefully away from the chassis. Remove the ribbon cable W1 from the A8 Motherboard. NOTE W1 may have locking springs on each side. Depress the spring on each side of the connector to remove from the motherboard.
  • Page 17 Installation Procedure Rear Panel Removal 1. Refer to Figure 8. Using the T-10 driver, remove the twenty screws (2) and (3) attaching the rear panel (1) to the chassis. The rear panel can now be removed. 2. Use a 9/16-inch socket wrench to remove the nut securing the EXT REF IN connector from the rear panel.
  • Page 18 Installation Procedure Top Brace and Reference Bracket 1. Refer to Figure 9. To remove the top brace (1) and reference bracket (2), use the T-10 driver to remove the twelve panhead screws (3) (0515-0372), six on each side, attaching the braces to the chassis.
  • Page 19 Installation Procedure RF Bracket Removal 1. Refer to Figure 10. Remove the RF bracket (1) by removing the remaining seven screws (2) using the T-10 driver. Figure 10 RF Bracket Removal Installation Note N9020-90239...
  • Page 20 Installation Procedure Removing Cables 1. Refer to Figure 11. Remove cable W50 connecting A3 Digital IF J17 to A16 Reference Assembly J726. Note cable routing from Digital IF J17 through the opening in the side panel. This cable will not be reused. 2.
  • Page 21 Installation Procedure Replace A16 Reference and A6 Power Supply Assemblies 1. Refer to Figure 12. Remove the cable ties securing the flexible coax cables and semi-rigid cables to each other above the A16 Reference Assembly. 2. Using a 5/16-inch wrench, disconnect each end of semi-rigid coax cables W5, W6, and W19. These cables will not be re-used.
  • Page 22 Installation Procedure 5. Refer to Figure 13 Figure 14. Remove the six screws (1) attaching the CPU assembly to the chassis. 6. Remove the CPU assembly from the chassis by pulling straight out the back. Use the two ejectors to pull the CPU assembly out from the chassis. Figure 13 Current CPU Assembly - Rear Panel View Installation Note...
  • Page 23 Installation Procedure Figure 14 Old CPU Assembly - Rear Panel View Installation Note N9020-90239...
  • Page 24 Installation Procedure 7. Refer to Figure 15. Remove the three screws (1) attaching the power supply (2) to the power supply bracket (3). Keep these screws; they will be used later. Figure 15 Power Supply Assembly Removal 8. Remove the power supply assembly from the chassis by pulling straight out the back. 9.
  • Page 25 Installation Procedure 13. Locate the new A16 Reference assembly, N9020-60200, in the kit. Slide the reference assembly into the slot at the rear of the instrument and push on the assembly to mate the connectors to the Midplane assembly. Secure with the ejector. 14.
  • Page 26 Installation Procedure 19. Refer to Figure 17. Locate the reference support bracket, E4410-00108 and 0515-0372 screw in the kit. Secure the reference support bracket to the A16 Reference assembly as shown. Torque to 9 inch-pounds. The original reference bracket will not be reused. Figure 17 Install Reference Support Bracket Installation Note...
  • Page 27 Installation Procedure 20. Refer to Figure 18. Remove cable W38 connecting A15 Front End Controller J901 to A3 Digital IF J15. Note cable routing from Digital IF through the attenuator brackets and switches. This cable will not be reused. Figure 18 W38, W40, W42, W43 Removal - Option B40, MPB, or DP2 21.
  • Page 28 Installation Procedure Replace A3 Digital IF 1. Disconnect any remaining cables from the bottom the A3 Digital IF assembly. 2. Refer to Figure 19. Pull the AIF/DIF assembly part way out of the chassis. Remove cables W13, W14, and W37 from the AIF assembly. 3.
  • Page 29 Installation Procedure 4. Refer to Figure 20. To separate the AIF (1) from the DIF (2), unplug ribbon cable W2 from the AIF assembly. 5. From underneath the assembly, remove the three screws (3). Figure 20 AIF/DIF Separation 6. Disconnect ribbon cable W2 from the DIF assembly. 7.
  • Page 30 Installation Procedure Installing Boards and Cables 1. Refer to Figure 21. Locate ribbon cable 8121-1854 (W57) and the A26 Wideband Digital IF in the kit. Connect W57 to the ribbon cable connector on the A26 Wideband Digital IF. 2. Install the A26 Wideband Digital IF into slot 4 by pressing the ejector. Lift the free end of the ribbon cable up as shown in Figure Figure 21...
  • Page 31 Installation Procedure 6. Refer to Figure 22. Locate W55 in the Opt HLB/HLC Cable Kit. This cable will have part number 8121-2290 and will have ends labeled “805” and “17”. Connect the end labeled “17” to A3J17 on the A3 DIF Assembly. Route the cable through cutout in the right side chassis near A10 Attenuator B and connect the other end to A25J805 on the A25 Wideband Analog IF Assembly.
  • Page 32 Installation Procedure 8. Refer to Figure 23. Locate W54 in the Opt HLB/HLC Cable Kit. This cable will have part number 8121-2288 and will have ends labeled “716” and “14”. Connect the end labeled “14” to A3J14 on the A3 Digital IF Assembly. Route the cable from the DIF board through the cutout in the right side chassis and connect the other end to A16J716 on the A16 Reference Assembly.
  • Page 33 Installation Procedure 9. Refer to Figure 24. Locate W56 in the Opt HLB/HLC Cable Kit. This cable will have part number 8121-2291 and will have ends labeled “806” and “726”. Connect the end labeled “806” to A25J806 on the A25 Wideband Analog IF Assembly. Route the cable along the right side chassis behind attenuators A9 and A10 and connect the other end to A16J726 on the A16 Reference Assembly.
  • Page 34 Installation Procedure 11. Refer to Figure 25. Locate W20 in the Opt HLB/HLC Cable Kit. This cable will have part number 8121-1400 and will have ends labeled “705” and “6”. Connect the end labeled “705” to A16J705 on the A16 Reference Assembly. Route the cable along the right side of the chassis as shown and connect the other end to A13J6 on the A13 Front End Assembly.
  • Page 35 Installation Procedure 13. Refer to Figure 26. Locate the cable clip (5041-9690) in the kit. Secure the coax cable clip to the right side chassis as shown. Figure 26 Installing Coax Cable Clip 14. Refer to Figure 27. Dress the coaxial cables neatly and snap into the cable clip with the correct sequence as shown in Figure 8.
  • Page 36 Installation Procedure Dressing Cables 1. Refer to Figure 28. Dress the coaxial cables and semi-rigid cables neatly and tie together using cable ties (1400-0249) at the locations indicated. Figure 28 Adding Cable Ties near A13 and A15 Assemblies 2. Refer to Figure 29.
  • Page 37 Installation Procedure 3. Refer to Figure 30. Install the semi-rigid coaxial cables cable clip as shown. Note that the rear-most semi-rigid cable, W6, should not be in cable clip, but the semi-rigid cable next to it, W19, should be in the rear-most position of the cable clip. Use two cable ties (1400-0249), one to the left of the cable clip and one to the right of the cable clip, to secure W6 and W19 together.
  • Page 38 Installation Procedure Reassembly 1. Refer to Figure 31. Reinstall the RF bracket (1) onto the chassis using seven screws (2). Torque to 9 inch-pounds. Figure 31 RF Bracket Replacement Installation Note N9020-90239...
  • Page 39 Installation Procedure 2. Refer to Figure 32. To replace the top brace (1), place it in the correct position and attach the appropriate screws. The kit includes six additional 0515-1227 flathead screws (6), (7) to secure the top brace to the A25, A26, and A16 assemblies. Torque to 9 inch-pounds. Figure 32 Top Brace Replacement 3.
  • Page 40 Installation Procedure 7. Refer to Figure 33. Place the rear panel (1) into position in the chassis. Replace the twenty screws (2) to attach the rear panel to the chassis. Torque to 9 inch-pounds. Figure 33 Rear Panel Replacement Installation Note N9020-90239...
  • Page 41 Installation Procedure 8. Refer to Figure 34. Reattach the ribbon cable W1. Figure 34 Front Panel Cable Installation Note N9020-90239...
  • Page 42 Installation Procedure 9. Refer to Figure 35. Carefully position the Front Frame Assembly onto the chassis. Ensure no cables are crushed. Replace the eight screws (1), four on each side of the chassis. Torque to 9 inch pounds. Figure 35 Front Frame Replacement Installation Note N9020-90239...
  • Page 43 Installation Procedure Final Installation for Standard Instruments (Benchtop Configuration, Figure 1. Refer to Figure 3. Carefully slide the instrument cover back onto the instrument from the rear of the analyzer, making sure not to damage any internal cables. The seam on the cover should be on the bottom of the instrument.
  • Page 44 Installation Procedure Power Up and New Hardware Wizard 1. Connect a keyboard and mouse to the instrument. 2. Power on the instrument. 3. During the boot up process you may notice that the “Found New Hardware” bubble appears in the lower right screen, and a “Found New Hardware’...
  • Page 45 Installation Procedure 5. Enter administrator as the user name, and agilent4u as the password. Select OK. 6. The screen in Figure 37 appears. Select Yes, This time only. Click Next. Figure 37 Installation Note N9020-90239...
  • Page 46 Installation Procedure 7. The screen in Figure 38 appears. Ensure “Install the software automatically’ is selected and click Next. Figure 38 8. The wizard will install the required software. Once you see the “Completing the Found New Hardware Wizard” screen appear, click Finish. Installation Note N9020-90239...

  • Page 47: Update The Instrument Software

    Installation Procedure Update the instrument Software NOTE Instrument software revision A.13.15 or later is required. 1. Loading the latest instrument software is required to assure all FPGAs and drivers located on both the newly installed hardware and on the base instrument are synchronized. Therefore, even if the instrument contains the latest revision of software, you must reinstall the software to assure proper operation.
  • Page 48 Installation Procedure Verify the Option 1. Turn the analyzer on and verify no errors are reported at power up through the power-on alignment of the analyzer. 2. Press Mode IQ Analyzer (Basic) 3. Press , or , if available). Mode Setup IF Path 85 MHz 125 MHz...

  • Page 49: Adjustments Required

    Utilities, Adjustments, and Performance Verification Tests Utilities, Adjustments, and Performance Verification Tests Calibration software and specified test equipment is required to perform the adjustments and can be used to automate the performance verification testing. Obtain Agilent X-Series Signal Analyzer Calibration Application SW, N7814A TME Calibration Application, version E.11.00 or later.
  • Page 50 Utilities, Adjustments, and Performance Verification Tests A full calibration is required to assure the instrument meets all specifications The end user must ultimately determine whether they want a full calibration to be performed. If a full calibration is required, arrangements regarding the level of the calibration must be made between the end user and the calibration provider.
