Glider N Ottoman
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
Consumer Care:
www.DeltaChildren.com
Delta Children's Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
To register your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.
NOVEMBER 7, 2011, 22289, R8
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.
Style #:
___________
Lot:
___________
Date:
___________
When contacting Delta Consumer
Care you will need to reference the
above numbers. They can also be
found on the label on the bottom of
Chair Back.
A
REV
FACTORY
©2011 DELTA ENTERPRISE CORP.
Advertisement
Related Manuals for Delta Children Glider N Ottoman
Summary of Contents for Delta Children Glider N Ottoman
- Page 1 KEEP INSTRUCTIONS FOR FUTURE USE. ADULT ASSEMBLY REQUIRED Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete. Glider N Ottoman THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE. Consumer Care: Style #: ___________ www.DeltaChildren.com...
- Page 2 P A R TS: MAKE SURE TH A T AL L PRE-ASSEMBLED P A R TS ARE TIGH T . C. RIGHT GLIDER ARM (1) B. LEFT GLIDER ARM (1) D. GLIDER BASE (1) A. GLIDER BACK FRAME (1) H. GLIDER SEAT F.
- Page 3 STEP 1 TURN THE GLIDER BASE (PART D) OVER, THEN ATTACH THE BOTTOM GLIDES (PART L) AS SHOWN. REMOVE THE BLACKING STRIP FROM ONE GLIDE AT A TIME AND ADHERE THE GLIDE TO THE BASE, REPEAT FOR ALL 4 GLIDES. STEP 2 ATTACH THE GLIDER BACK FRAME (PART A) TO THE GLIDER SEAT (PART E) USING (4) 1/4”...
- Page 4 STEP 3 ATTACH THE LEFT GLIDER ARM (PART B) AND THE RIGHT GLIDER ARM (PART C) TO THE GLIDER SEAT USING (2) 1/4” x 1-3/8” BOLTS (PART M) EACH (FIGURE A). DO NOT TIGHTEN BOLTS. INSTALL A BARREL NUT (PART P) IN THE HOLE AT THE BACK OF EACH ARM (FIGURE B).
- Page 5 STEP 4 ATTACH THE ASSEMBLES FROM STEP 3 TO THE GLIDER BASE USING (8) 1/4” x 1-3/8” BOLTS (PART M) AS SHOWN IN FIGURE A & B. TIGHTEN WITH THE M4 ALLEN WRENCH. FIGURE A FIGURE B...
- Page 6 STEP 5 ATTACH (1) LEFT GLIDER ARM CUSHION (PART F) TO THE LEFT GLIDER ARM. WITH THE SNAPS ON THE GLIDER ARM CUSHION FACING UP, SLIDE THE GLIDER ARM CUSHION UNDER THE GLIDER ARM AND SNAP ALL (3) SNAPS INTO PLACE. FOLD THE GLIDR ARM CUSHION UNDER THE BOTTOM, THEN OVER TOP OF THE GLIDER ARM AS SHOWN.
- Page 7 STEP 7 ATTACH THE OTTOMAN CUSHION (PART K) TO THE OTTOMAN BASE (PART J) USING (4) 1/4” x 1-3/8” BOLTS (PART M), TIGHTEN WITH THE M4 ALLEN WRENCH. FINAL...
- Page 8 - MACHINE WASHING IS NOT RECOMMENDED. WOOD : - DO NOT SCRATCH OR CHIP THE FINISH. - INSPECT PERIODICALLY, CONTACT DELTA CHILDREN'S PRODUCTS FOR REPLACEMENT PARTS OR QUESTIONS. - DO NOT STORE ANY PARTS IN EXTREME TEMPERATURES AND CONDITIONS SUCH AS A HOT ATTIC OR A DAMP, COLD BASEMENT.
