Amber/white led halo passing lamp

Advertisement

3
4
5
Questions? Call us at: 1 (800) 382-1388
Installation Instructions - Page 2
Installation:
7.
8.
9.
10. Remove the top 3 T27 Torx Bolts from the outer fairing as shown
11. Reinstall the center T27 Torx Bolt only that was removed in Step
12. While standing in front of the bike and holding the fairing, remove
13. With the fairing slightly pulled away from the bike, disconnect the
14. With the fairing removed, Locate the connectors on the inner fair-
15. With the AW Converter harness installed to the factory wiring
16. Reinstall the fairing and windshield in the reverse order that it
17. Check operation of the Amber/White LED Halo Passing Lamps,
M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
Route the Passing Lamp harness through the notch in in the back
of the Turn Signal housing along with the factory harness, refer to
Picture 3. Reinstall the 2 Turn Signal Housing mounting screws.
Use caution not to pinch the harnesses during this step.
Repeat Steps 3-7 for the opposite side.
Cover the passing lamps with a soft cloth to protect them and the
fairing from being damaged during the fairing removal.
in Picture 4. Remove the windshield and store it in a safe place for
reinstallation later.
10. Lightly tighten the center bolt to secure the fairing while you
remove the remaining 4 inner fairing bolts. Remove the 4 inner
fairing bolts. The lower 2 inner fairing bolts are located on the
lower triple tree as shown in Picture 5. Refer to Picture 6 for the
upper 2 inner fairing bolts.
the center outer fairing T27 Torx bolt and pull the fairing slightly
away from the bike.
connector from the headlamp as shown in Picture 7. Lay the fair-
ing on a protected flat surface to prevent damage.
ing that go to each of the front turn signals. The connectors are
located in the areas circled in Picture 8. Unplug the connectors
and connect the pass-through side of the AW Converter Harness
to the factory turn signal wiring harness.
harness, connect the passing lamp harness to the AW Converter
harness. With the zip ties provided, secure the passing lamp wire
to the turn signal and passing lamp factory wiring as shown in
Picture 9. Secure the harnesses to prevent the wires from being
damaged during the fairing installation as shown.
was removed.
turn signals and passing lamps in all modes.
07-2019
