Custom Dynamics TruWrapz Installation Instructions

Yamaha Stryker TruWrapz® Installation Instructions.
Notice: This product is designed and intended for use as auxiliary lighting on motorcycles only. This
product is NOT intended to replace any original equipment lighting installed on the motorcycle and
should not be used for that purpose. This product must be wired such that it does not interfere with any
original equipment lighting.
1) Using a suitable motorcycle frame jack support the motorcycle until the front wheel is
just barley touching the ground and all weight has been removed from it by following
jack manufacturers instructions for proper jack usage.
2) Once properly supported remove the headlight by removing the screws on each side of
the head light bucket
3) Following the instructions contained within the TrueWrapz package, install the
TruWrapz® onto each fork tube and route their wires inside the headlight bucket.
4) Once installed and the wires are routed, locate the connector for the right side turn signal
and use the supplied Posi-Tap connector to tap into the right side turn signal wire. This
wire should be a GREEN WIRE WITH YELLOW DOTS ON IT. If there is any
confusion use a test light to confirm which wire is the turn signal wire. (see pic #23)
5) Next repeat this procedure for the left side turn signal wire which should be a BROWN
WIRE WITH YELLOW DOTS on it.
6) Next using ether turn signal connector harness attaches a Posi-Tap connector onto the
blue wire and a Posi-Tap onto the black wire.
7) Using one of the 2 supplied Eclipze™ units, take the orange wire from the 3 wire end of
the Eclipze unit and hook it into the Posi-Tap connector going to the right side turn signal
wire.(green wire with yellow dots) (see pic #23)
8) Next take the same orange wire from the remaining Eclipze™ and hook it into the Posi-
Tap connector going to the left side Turn signal wire (brown with yellow dots)
9) Take the two red wires from the 3 wire end of both the Eclipze™ units and twist them
together then attach them to the Posi-Tap connector going to the running light circuit
which is the BLUE wire. (see pic# 24)
10) Then take the two black wires coming from the 3 wire end of the 2 Eclipze™ units twist
them together and attach them to the Posi-Tap connector going to the black wire. (see pic
# 25)
11) Next, take the two wires coming from the TruWrapz® on the left side and hook them
onto the two output wires coming from the Eclipze™ unit hooked to the left side turn
signal connector as follows. Yellow wire from TruWrapz® to the red output wire from
