  • Page 1 WDAT-iZ4 120.1 - 580.2 R1234ze...
  • Page 2 Dear Customer, We congratulate you on choosing these product Clivet has been working for years to offer systems able to assure the maximum comfort for a long time with highly-reliable, efficient, high-quality and safe solutions. The target of the company is to offer advanced systems, that assure the best comfort and reduce energy consumption as well as the installation and maintenance costs for the entire life-cycle of the system.

  • Page 3: Table Of Contents

    Safety considerations Before installation Selecting the installation site Water connections Electrical connections Start-up Control Maintenance 9 Antivibration mounts 10 Rilevatore perdite refrigerante 11 Decommissioning 12 Residual risks 13 Technical data...

  • Page 4: Safety Considerations

    1 SAFETY CONSIDERATIONS Pay particular attention to: Manual The manual provides correct unit installation, use and warnings / prohibitions / danger indicating particularly important maintenance. operations or information, operations It is advisable to read it carefully so you will save time during that cannot be done, which compromise operations.
  • Page 5 1 SAFETY CONSIDERATIONS Modification All unit modifications will end the warranty coverage and the manufacturer responsibility. Breakdown/Malfunction Disable the unit immediately in case of breakdown or malfunction. Contact a certified service agent. Use original spares parts only. Using the unit in case of breakdown or malfunction: voids the warranty it may compromise the safety of the unit it may increase time and repair costs...
  • Page 6 1 SAFETY CONSIDERATIONS The installer must train the user, particularly on: Start-up/shutdown Set points change Standby mode Maintenance What to do / what not to do in case of breakdown Unit identification The serial number label is positioned on the unit and allows to indentify all the unit features.

  • Page 7: Before Installation

    2 BEFORE INSTALLATION Reception You have to check before accepting the delivery: That the unit hasn’t been damaged during transport That the materials delivered correspond with that indicated on the transport document comparing the data with the identification label positioned on the packaging. In case of damage or anomaly: write down on the transport document the damage you found and quote this sentence: “Conditional acceptance clear...
  • Page 8 2 BEFORE INSTALLATION Handling Check that all handling equipment complies with local safety regulations (cran, forklifts, ropes, hooks, etc.). Provide personnel with personal protective equipment suitable for the situation, such as helmet, gloves, accident-prevention shoes, etc. Observe all safety procedures in order to guarantee the safety of the personnel present and the of material.

  • Page 9: Selecting The Installation Site

    3 SELECTING THE INSTALLATION SITE Positioning Installation must be in accordance with local regulations. If they do not exist, follow EN378 . During positioning consider these elements: customer approval unit weight and bearing point capacity safe accessible position functional spaces spaces for the air intake/exhaust electrical connections max.
  • Page 10 3 SELECTING THE INSTALLATION SITE Avoid therefore: obstacles to the airflow exchange difficulties leaves or other foreign bodies that can obstruct the exchange batteries winds that hinder or favour the airflow heat or pollution sources close to the unit (chimneys, extractors etc) stratification (cold air that stagnates at the bottom) recirculation (expelled air that is sucked in again)

  • Page 11: Water Connections

    4 WATER CONNECTIONS Hydraulic system The pipes must be designed and manufactured to limit pressure drops as much as possible, i.e. optimise performance of the system. Keep the following to a minimum: overall length number of bends number of vertical changes of direction The warranty does not cover If the unit is to replace an existing unit, clean the system damages caused by limestone...
  • Page 12 4 WATER CONNECTIONS Risk of freeze If the unit or the relative water connections can be subject to temperatures close to 0°C: Mix water with ethylene glycol, or The unit must always be protected Safeguard the pipes with heating cables placed under the from freeze.
  • Page 13 4 WATER CONNECTIONS Flow Switch The flow switch must be present to ensure shutdown of the unit if Flow switch water is not circulating. It has to be installed in a duct rectilinear part, not in proximity of curves that cause turbulences. Operations sequence Before starting the unit pump: 1 Close all vents in the high points of the unit’s water circuit.
  • Page 14 4 WATER CONNECTIONS Standard unit Unit + pump exchanger chemical cleaning bypass 14 pressure gauge exchanger system cleaning bypass 15 check valve antifreeze heater 10 vent 16 pump water temperature probes 11 drain 17 safety valve 12 water flow switch 18 shut-off valves differential pressur switch 13 system loading safety pressure...
  • Page 15 4 WATER CONNECTIONS Partial energy recovery Option A configuration which enables the production of hot water free-of- charge while operating in the cooling mode, thanks to the partial recovery of condensation heat that would otherwise be rejected to the external heat source. The maximum capacity available from the partial recovery is equal to the 15% of the rejected heating capacity (cooling capacity + compressor power input)

  • Page 16: Electrical Connections

    5 ELECTRICAL CONNECTIONS The characteristics of the electrical lines must be determined by specialized personnel able to design electrical installations; moreover, the lines must be in conformity with regulations in force. The protection devices of the unit power line must be able to stop the presumed short circuit current, whose value must be determined in function of system features.
  • Page 17 5 ELECTRICAL CONNECTIONS Signals / data lines Do not overpass the maximum power allowed, which varies, according to the type of signal. Lay the cables far from power cables or cables having a different tension and that are able to emit electromagnetic disturbances. Do not lay the cable near devices which can generate electromagnetic interferences.
  • Page 18 5 ELECTRICAL CONNECTIONS...
  • Page 19 5 ELECTRICAL CONNECTIONS Computer connection Configure P.C. 1 connect P.C. and main module with LAN cable 2 check in the taskbar that the connection is active 3 open Control Panel and select Network and sharing center 4 select Modify board setting 5 select Local area connection (LAN) 6 select Internet protocol version 4 (TPC) IPV4 and enter Property...
  • Page 20 5 ELECTRICAL CONNECTIONS Remote Control Option 1 Distance up to 350 mt 2 Distance up to 700 mt User interface B=B1 KNX bus, max 350 mt twisted pair with shield, ø 0,8 mm EIB/KNX cable marking recommended PSX - Mains power supply unit power supply unit N125/11 5WG1 125-1AB11 AC 120...230V, 50...60Hz KNX bus, max 350 mt...
  • Page 21 5 ELECTRICAL CONNECTIONS Modbus - RS485 Option LED BSP communication with AP1 module LED BUS communication with Modbus green communication ok green communication ok yellow software ok but communication with AP1 down yellow startup / channel not communicating flashing: software error communication down fixed: hardware error Modbus / LonWorks / Cable requirements...

  • Page 22: Start-Up

    6 START-UP General indicated operations should done qualified technician with specific training on the product. The electrical, water connections and the other system works are by the installer. Agree upon in advance the start-up data with the service centre. Agree upon in advance the star-up data with the service centre. For details, refer to the various chapters in the manual.
  • Page 23 6 START-UP Preliminary checks Unit OFF power supply Yes / No safe access suitable frame to withstand unit weight + people weight functional clearances air flow: correct return and supply (no bypass, no stratification) considered level to be reachable by snow considered main winds lack of chimneys/corrosive atmospheres/pollutants structure integrity...
  • Page 24 6 START-UP Start-up sequence Unit power supply ON Yes / No compressor carter resistances operating at least since 8 hours off-load voltage measure phase sequence check pump manual start-up and flow check refrigeration circuit shut-off valves opening (if applicable) unit ON load voltage measure verify the lack of bubbles in the liquid light (if applicable) check of all fan operating...
  • Page 25 6 START-UP Cooling circuit 1 Visually inspect the refrigerating circuit: the presence of oil stains can by a symptom of leakage (caused e.g. by transportation, handling or other). 2 Verify that the refrigerating circuit is in pressure: Using the unit manometers, if present, or service manometers. 3 Make sure that all the service outlets are closed with proper caps;...
  • Page 26 6 START-UP Compressor casing resistances Connect the compressor oil heating resistances at least 8 hours before the compressor is to be started: at the first unit start-up after each prolonged period of inactivity 1 Power the heaters: isolator switch on 1 / ON. 2 Check the power consumption of the resistances to make sure that they are functioning.
  • Page 27 6 START-UP Demand limit Menu accessible only after having entered the password. Access reserved only to specifically trained personnel. The parameter modification can cause irreversible damages. It is possible to limit the absorbed electric power with an external signal 0-10 Vcc or 4-20mA. The higher the signal is, the lower the number of compressors available to meet the thermal need.
  • Page 28 6 START-UP Climatica TExt Menu accessible only after having entered the password. Access reserved only to specifically trained personnel. The parameter modification can cause irreversible damages. The setpoint based on the climatic curve and the Water Reset is displayed on the display Only if P0053: En Climatica = 1 Path: Main menu / Unit parameters / Options Path: Main menu / Unit parameters / Climatic TExt Parameters...
  • Page 29 6 START-UP Water reset Menu accessible only after having entered the password. Access reserved only to specifically trained personnel. The parameter modification can cause irreversible damages. It is possible to limit the absorbed electric power with an external signal 0-10 Vcc or 4-20mA. The setpoint based on the climatic curve and the Water Reset is displayed on the display Only if P0051: En WaterReset = 1...
  • Page 30 In the event of a compressor breakdown due to operating in the above-mentioned conditions, the warranty shall not be valid and Clivet spa declines any responsibility. Periodically check the average operating times and frequency of compressor start-ups: indicatively the minimum thermal load must be such as to require a compressor to operate for at least ten minutes.
  • Page 31 6 START-UP Start-up report To detect the objective operational conditions is useful to control the unit over time. With unit at steady state, i.e. in stable and close-to-work conditions, identify the following data: total voltages and absorptions with unit at full load absorptions of the different electric loads (compressors, fans, pumps etc) temperatures and flows of the different fluids (water, air) both...

  • Page 32: Control

    7 CONTROL...
  • Page 33 7 CONTROL...
  • Page 34 7 CONTROL...
  • Page 35 7 CONTROL...
  • Page 36 7 CONTROL...
  • Page 37 7 CONTROL...
  • Page 38 7 CONTROL...
  • Page 39 7 CONTROL...

  • Page 40: Maintenance

    8 MAINTENANCE SAFETY WARNINGS FOR OPERATIONS ON UNITS CONTAINING R1234ze Area checks Before working on systems containing flammable refrigerants, perform safety checks to reduce the risk of combustion to the minimum. Before performing any reparation operations on the cooling system, comply with the following warnings.
  • Page 41 MAINTENANCE containing refrigerant, unless they are manufactured with material intrinsically resistant to corrosion or suitably protected against corrosion. Electrical device checks The reparation and maintenance of electric components must include initial safety checks and component inspection procedures. In case of a fault that compromises safety, do not perform any electrical connection to the circuit until said fault is suitably resolved.
  • Page 42 8 MAINTENANCE Check that the detector is not a possible source of ignition and that it is suitable for the refrigerant. Leak detection equipment must always be set to an LFL percentage and calibrated depending on the refrigerant used, so the correct gas percentage (25% max) must be verified. Leak detection fluids are suitable for most refrigerants, although using detergents containing chlorine should be avoided as this substance may react with the refrigerant and corrode copper pipes.
  • Page 43 MAINTENANCE Before attempting the procedure, check that: The mechanical manipulation equipment is available, if necessary, to handle refrigerant tanks; All the personal protection equipment is available and employed correctly; The recovery procedure is monitored at all times by skilled personnel; The recovery equipment and tanks comply with suitable standards.
  • Page 44 MAINTENANCE 4 Storage of equipment/devices The equipment must be stored in compliance with the instructions provided by the manufacturer. 5 Storing packed (unsold) equipment Packing must be performed in such a way that mechanical damage to the equipment inside it does not cause refrigerant leaks.
  • Page 45 MAINTENANCE General Maintenance must be performed by authorized centres or by qualified personnel The maintenance allows to: maintaining the unit efficient reduce the deterioration speed all the equipment is subject to over time collect information and data to understand the efficiency state of the unit and prevent possible faults WARNING Before checking, please verify the following:...
  • Page 46 MAINTENANCE intervention frequency (months) Presence of corrosions Panel fixing Fan fixing coil cleaning Water filter cleaning water: quality, pH, glycol concentration check exchanger efficiency circulation pump Check of the fixing and the insulation of the power lead 10 earth cable check 11 Electric panel cleaning 12 power remote controls status 13 clamp closure, cable isolation integrity...
  • Page 47 MAINTENANCE Unit booklet Foresee a unit schedule to keep trace of the interventions made on the unit. In this way, it will be easier to adequately schedule the various interventions and facilitate any troubleshooting. On the schedule note: date intervention description carried out measures etc.
  • Page 48 MAINTENANCE Compressor casing heater Check: closure Operation water side heat exchanger The exchanger must to be able to provide the maximum thermal exchange, therefore it is essential for the inner surfaces to be clean of dirt and build-up. Periodically check the difference between the temperature of the supply water and the condensation temperature: if the difference is greater than 8°C–10°C it is advisable to clean the exchanger.
  • Page 49 MAINTENANCE Air coil Accidental contact with the exchanger fins can cause cuts: wear protective gloves. The coil must allow maximum thermal exchange, therefore, the surface must be clear from dirt and scaling. It is recommended a quarterly cleaning of the coils, as the minimum.
  • Page 50 MAINTENANCE Electric fans Check: the fans and the relative protection gridsare well fixed the fan bearings (evident by noise and anomalous vibrations) the terminal protection covers are closed and the cable holders are properly positioned. Screw compressors - Periodical checks Compressor supply line shut-off valve Do not remove the seal Remove only if authorized by the manufacturer.
  • Page 51 MAINTENANCE Compressor replacement...
  • Page 52 ANTIVIBRATION MOUNTS...
  • Page 53 ANTIVIBRATION MOUNTS...
  • Page 54 ANTIVIBRATION MOUNTS...
  • Page 55 REFRIGERANT LEAK DETECTOR Option present with compressor box For specific information refer to the component manufacturer's manual.. Maintenance The inspection must be carried out by qualified service personnel. Check the correct operation of the LEDs. Check the correct functioning of the buzzer and relay. Check the signal transmission to the central BMS / controller, if connected.
  • Page 56 DECOMMISSIONING Disconnection WARNING Before performing any operation, read the warnings found in the Maintenance chapter. Avoid leak or spills into the environment. Before disconnecting the unit, the following must be recovered, if present: refrigerant gas Warning: Anti-freeze solutions in the hydraulic circuit Fire hazard Awaiting decommissioning and disposal, the unit can also be stored Flammable materials...
  • Page 57 RESIDUAL RISKS General In this section the most common situations are indicated,as these cannot be controlled by the manufacturer and could be a source of risk situa- tions for people or things. Danger zone This is an area in which only an authorised operator may work. The danger zone is the area inside the unit which is accessible only with the deliberate removal of protections or parts thereof.
  • Page 58 RESIDUAL RISKS Do not remain in the vicinity of the safety valve and never leave the refri- ger-ating system taps closed. Electric parts An incomplete attachment line to the electric network or with incorrectly sized cables and/or unsuitable protective devices can cause electric shocks, intoxication, damage to the unit or fires.
  • Page 59 General technical data performance - Standard acoustic configuration (ST) / Compressor soundproofing (SC) 120.1 160.1 200.1 240.1 290.1 250.2 280.2 320.2 360.2 400.2 440.2 480.2 540.2 580.2 SIZE Cooling capacity 1056 Compressor power input 59,1 79,6 Total power input 64,0 84,5 Partial recovery heating capacity 26,3...
  • Page 60 General technical data sound levels - Standard acoustic configuration (ST) SOUND POWER LEVEL (dB) - Octave band (HZ) Sound power level Sound pressure level SIZE 1000 2000 4000 8000 dB(A) dB(A) 120.1 160.1 200.1 240.1 290.1 250.2 280.2 320.2 360.2 400.2 440.2 480.2...
  • Page 61 General technical data Minimum (Qmin) and maximum (Qmax) admissible water flow for the unit to operate correctly. 120.1 160.1 200.1 240.1 290.1 250.2 280.2 320.2 360.2 400.2 440.2 480.2 540.2 580.2 Qmin [l/s] 10,5 11,6 11,6 12,7 15,2 14,3 15,2 18,5 19,8 23,3...
  • Page 62 General technical data Ta (°C) = external exchanger inlet air temperature (D.B.) To (°C) = internal exchanger outlet water temperature 1. Standard unit operating range at full load 2. Standard unit operating range with air flow automatic modulation Ta (°C) = external exchanger inlet air temperature (D.B.) To (°C) = internal exchanger outlet water temperature 1.
  • Page 63 Dimensional drawings SIZE 120.1 - 160.1 ST-SC DAA5Z0009 REV00 DATA/DATE 30/10/2019 1. Internal exchanger (evaporator) 2. External exchanger (condenser) 3. Unit fixing holes 4. Lifting brackets (removable) 5. Electrical panel 6. Power input 7. Sound proof enclosure, only SC version 8.
  • Page 64 Dimensional drawings SIZE 200.1 - 240.1 ST-SC 1. Internal exchanger (evaporator) 2. External exchanger (condenser) 3. Unit fixing holes 4. Lifting brackets (removable) 5. Electrical panel 6. Power input 7. Sound proof enclosure, only SC version 8. Clearance access recommended 200.1 240.1 SIZE...
  • Page 65 Dimensional drawings SIZE 290.1 ST-SC 1. Internal exchanger (evaporator) 2. External exchanger (condenser) 3. Unit fixing holes 4. Lifting brackets (removable) 5. Electrical panel 6. Power input 7. Sound proof enclosure, only SC version 8. Clearance access recommended 290.1 SIZE Length 5425 5425...
  • Page 66 Dimensional drawings SIZE 250.2 - 280.2 - 320.2 ST-SC 1. Internal exchanger (evaporator) 5. Electrical panel 2. External exchanger (condenser) 6. Power input 3. Unit fixing holes 7. Sound proof enclosure, only SC version 4. Lifting brackets (removable) 8. Clearance access recommended 250.2 280.2 320.2...
  • Page 67 Dimensional drawings SIZE 360.2 - 400.2 ST-SC 1. Internal exchanger (evaporator) 5. Electrical panel 2. External exchanger (condenser) 6. Power input 3. Unit fixing holes 7. Sound proof enclosure, only SC version 4. Lifting brackets (removable) 8. Clearance access recommended 360.2 400.2 SIZE...
  • Page 68 SIZE 440.2 - 480.2 ST-SC 1. Internal exchanger (evaporator) 5. Electrical panel 2. External exchanger (condenser) 6. Power input 3. Unit fixing holes 7. Sound proof enclosure, only SC version 4. Lifting brackets (removable) 8. Clearance access recommended 440.2 480.2 SIZE Length 7925...
  • Page 69 Dimensional drawings SIZE 540.2 ST-SC 1. Internal exchanger (evaporator) 5. Electrical panel 2. External exchanger (condenser) 6. Power input 3. Unit fixing holes 7. Sound proof enclosure, only SC version 4. Lifting brackets (removable) 8. Clearance access recommended 540.2 SIZE Length 9175 9175...
  • Page 70 Dimensional drawings SIZE 580.2 ST-SC 1. Internal exchanger (evaporator) 5. Electrical panel 2. External exchanger (condenser) 6. Power input 3. Unit fixing holes 7. Sound proof enclosure, only SC version 4. Lifting brackets (removable) 8. Clearance access recommended 580.2 SIZE Length 10425 10425...
  • Page 72 OFFERING SOLUTIONS TO ENSURE SUSTAINABLE COMFORT AND THE WELL-BEING OF PEOPLE AND THE ENVIRONMENT www.clivet.com M05Z00003-00 - 09-03-20 CLIVET SPA Via Camp Lonc 25, Z.I. Villapaiera 32032 Feltre (BL) - Italy Tel. +39 0439 3131 - Fax +39 0439 313300 info@clivet.it...
