Precautions for Installing the Car Mounter
Do Not Install This Product in
Unstable State
If balance of the unit is lost, it may
fall over or drop, resulting in an in-
jury.
Install the Car Mounter horizontally.
Bottom Side

Dimensional Drawing

Installation holes are provided in the areas indicated by the arrows in the fi gure above.
4
Do Not Install This Product
Wherever There is a Lot of Wa-
ter, Moisture, Steam, Dust, Oily
Vapors, etc.
Otherwise, possibly resulting in
fi re or electric shock.
CAUTION
The ends of the screws are
protruding. Take care to pro-
tect your fingers, etc. from
their sharp points when in-
stalling the Car Mounter.
