D1 ON/STAND-BY (on/off) button
D2 SILENT button
D3 Air flow button
D4 Decrease button
D5 Countdown Timer
D6 MODE button
D7 Increase button
D8 ECO REAL FEEL button
D9 Swing button (flap swing)
D10 Indication LED
USING THE CST REMOTE CONTROL
The CST remote control is an innovative technology that allows
a better wellbeings regulation, thanks to the sensors provided.
In order to optimize the wellbeings conditions around you, we
suggest you to keep it near you.
•
The remote control must be no more than about 10 meters
away from the appliance (fig. 10) (even in non line of sight).
The maximum range may be lower depending on the envi-
ronment. It belongs to Bluetooth class 2 device class.
•
The CST remote control must be handled with care. Do not
drop it or expose it to direct sunlight or sources of heat. It
is advisable to keep the CST remote Control Unit lied over a
table or a plan surface.
Do not hold the CST remote Control in your hand for long
time to avoid altering the reading of the sensors.
The CST sensors are also disabled if the CST remote control
is positioned at a distance less than 1 m from the unit.
•
The CST remote control is equipped with touch sensitive
buttons.
•
The CST remote control is equipped with a double color built-
in LED (D10) (white/red). White indications are used for:
-
signaling the touching of each button with 3 fast
flashes
-
every 30 seconds it blinks for data transmission
-
signaling the entering of pairing phase with periodic
blinking
-
signaling the batteries good status
•
The same indications but in red color mean that the batter-
ies begin to be exhausted.
Please note: The remote control can be safely stored in the ap-
propriate compartment (A11).
TURNING THE APPLIANCE ON/OFF
•
Plug into the outlet.
•
Touch the
ON/STAND-BY button (D1). When turned on,
the air conditioner starts operating in the same mode as
when it was turned off.
•
Touch the
ON/STAND-BY button (D1) again to switch the
appliance off.
C5
C6
C7
C5
C9
C6
C7
C12
C9
C13
C12
C11
C13
C4
C11
C1
C4
C1
C3
Please note: Never switch the appliance off by removing the
C2
plug. Always switch it off by touching the
ton (D1) and waiting few minutes before removing the plug.
Only in this way the appliance will perform the standard check-
ings.
SELECTING THE OPERATING MODES
The operating modes available on the CST remote control
through the MODE button (D6) correspond to those on the ap-
pliance control panel (C).
SELECTING THE TEMPERATURES
In conditioning mode touch button (D4) or (D7) to select
the desired temperature.
SELECTING THE AIR FLOW
In conditioning and fan modes, touch
the desired air flow.
The air flows available are:
Minimum air flow: when most silent operation is
desired.
Medium air flow: when the noise level needs to
be low but with a good comfort level.
Maximum air flow: for maximum performance.
Auto air flow
chooses the air flow based on the temperature
selected and the environmental conditions. This
selection is only available in conditioning mode.
ECO REAL FEEL FUNCTION
ECO REAL FEEL is the innovative De'Longhi technology that
works simultaneously on temperature reduction and humidity
control, securing best comfort level. With traditional systems,
during working time, optimal comfort conditions may be
reached but not secured over time. With ECO REAL FEEL, once
optimal comfort is reached, PAC automatically modulates com-
pressor action and air flow, to keep it over time.
To activate the function, touch the
control and the ECO REAL FEEL symbol appears.
After approx. 1 minute, the ECO REAL FEEL indicator (C11) turns
on. It changes color when approaching the best comfort level
(see following diagram).
Please note: For this type of use, the appliance must be set up as
for air conditioning mode.
16
C4
C1
ON/STAND-BY but-
button (D3) to select
:
the appliance automatically
button (D8) on remote
