- Page 1 Positioning & Support USER MANUAL i2i Head & Neck Positioning System Stealth’s User Manual and Maintenance Guide for the i2i Head & Neck Positioning System...
-
Page 2: Customer Satisfaction
Customer Satisfaction Stealth Products strives for 100% customer satisfaction. Your complete satisfaction is important. Please contact us with feedback or suggested changes that will help improve the quality and usability of our products. You may reach us at: Stealth Products, LLC... - Page 3 Important Information Important Information! All persons responsible for fitting, adjustment, and daily use of the devices discussed in these instructions must be familiar with and understand all safety aspects of the devices mentioned. In order for our products to be used successfully, you must: ...
-
Page 4: Introduction
Ordering Documentation You can download additional copies of this User Manual on the Stealth website: https://stlpro.site/stealth-docs and search: i2i User Manual in the search bar at the top of the page. -
Page 5: Warranty
Warranty Our products are designed, manufactured, and produced to the highest of standards. If any defect in material or workmanship is found, Stealth Products will repair or replace the product at our discretion. Any implied warranty, including the implied warranties of merchantability and fitness for a particular purpose, shall not extend beyond the duration of this warranty. -
Page 6: Table Of Contents
9.1 Chin Prompt ......................3 9.2 Proper Use ....................... 3 9.3 Fitting ......................... 4 10.0 i2i Head Positioning ................5 10.1 Indications for Use ..................... 5 10.2 Recommendation & Fitting ................5 10.3 Installing the Seat Back Mount ..............6... - Page 7 Table of Contents 11.0 Mounting & Adjusting ................ 7 11.1 Mounting Head Positioning to Hardware ..........7 11.2 Link Hardware ..................... 7 11.3 Flip Down Hardware ..................8 11.4 Offset Link Hardware ..................8 12.0 First Time Use ..................9 12.1 Dealer Assistance ....................
-
Page 8: Warning Labels
Limited Liability Stealth Products, LLC accepts no liability for personal injury or damage to property that may arise from the failure of the user or other persons to follow the recommendations, warnings, and instructions in this manual. -
Page 9: Hardware Positioning
Vertical round stem with anti-rotation notch and flip down mechanism Triangle clamp– needs to be positioned so it is even with the top of the seat back. When the i2i is flipped down, the hardware will clear the top of the back, preventing a potential safety hazard. ... -
Page 10: Part Numbers
Part Numbers Pediatric Small Medium Large Extra Large i2i280 i2i480 i2i580 i2i680 i2i780 i2i282 i2i482 i2i582 i2i382 i2i782 i2i380 i2i430 i2i530 i2i630 i2i781 i2i382 i2i432 i2i532 i2i632 i2i783 i2i481 i2i581 i2i681 i2i790 i2i483 i2i583 i2i683 i2i792 i2i490 i2i590 i2i690 i2i740 i2i492 i2i592 i2i692... -
Page 11: Design And Function
Design and Function Chin Prompt The Chin Prompt is to be used only with direct supervision. It is intended to be used only as a therapeutic tool, or for additional assistance for feeding, communication, therapy, and limited periods of time to increase the users ability to attend to an activity. -
Page 12: Fitting
Design and Function Fitting If the client requires less assistance support from the prompt, place the prompt just below the chin, using it as a boundary to limit the amount of neck flexion that the client might otherwise lapse into. The curved part of the Chin Prompt faces the neck. -
Page 13: I2I Head Positioning
Head & Neck Positioning System. The i2i is not intended to function like a custom molded seat for the head. It is designed to allow freedom of movement of the neck, but set some boundaries to limit neck extension, lateral flexion, and forward flexion. -
Page 14: Installing The Seat Back Mount
Head Positioning 10.0 There should be approximately 1/4” to 1/2” of clearance between the head positioning and your client’s body. WARNING Do not position in a way that will apply any force on the body in any area. -
Page 15: Mounting & Adjusting
11.1 To mount the i2i to the hardware: Place the 17mm ball into the designated socket in the rear of the i2i. Place the split ring around the ball and insert the four socket head screws (B) through the ring and into the threaded holes in the rear of the i2i. -
Page 16: Flip Down Hardware
Mounting & Adjusting 11.0 Flip Down Hardware 11.3 To use the flip down function: Pull down on the red sleeve (D). The hardware will flip down. The hardware will automatically lock into place when returning to the upright position. Offset Link Hardware 11.4 The offset link hardware offers the same adjustability as the standard link hardware but uses 15mm square tubing and adds a posterior offset. -
Page 17: First Time Use
(the user and/or the attendant). If needed, the dealer can make final adjustments. NOTICE After installation of the i2i, check that the hardware is in tact, that nothing is damaged, and that the wheelchair operating system is still fully functioning. User Testing 12.2... -
Page 18: Maintenance
Maintenance 13.0 Cleaning 13.1 To wash the i2i cover: Remove the cover from the i2i Machine wash in cold water on delicate cycle and drip dry. To wash sheepskin covers: Remove the cover from the i2i ... - Page 19 NOTES 14.0...
- Page 20 Stealth Products, LLC. • info@stealthproducts.com • www.stealthproducts.com +1(800) 965-9229 | +1(512) 715-9995 | 104 John Kelly Drive, Burnet TX 78611 P91D183 Revision Date 2019-12-17...
