- Page 1 Pump Installation and Service Manual OSP50/OSP50AB Submersible Effluent Pumps NOTE! To the installer: Please make sure you provide this manual to the owner of the pumping equipment or to the responsible party who maintains the system.
-
Page 2: General Information
2. Risk of Electrical Shock: 7. For proper automatic operation, General make sure the pump power Connect only to a properly Information cord is plugged into the grounded receptacle. piggyback receptacle on the Septic tank is to be vented diaphragm switch cord. in accordance with local Thank you for purchasing your 8. -
Page 3: Pump Installation
Pump Installation OSP50 Shown... -
Page 4: Pump Servicing
possible, any dirt or trash from blockage, the foot and baffle Pump the outside of the pump before plate must be removed by Servicing dismantling. removing the three hex head cap screws (29) and the bottom plate removed by 2. Check diaphragm switch. If Read the following instructions removing the five hex head the unit is being operated by... - Page 5 Hydromatic pumps have a continuity test, must the seal and lifting it off small air vent hole in the be replaced. without damaging seal. Inspect impeller cavity to let out the seal face for any nicks or trapped air. If this hole an uneven seating of seal face.
- Page 6 18.Reinstall the stator. Place the Do not fill the motor housing Pump stator (15) in the volute case completely — allow airspace Servicing (21) so the stator bolt holes for oil expansion. line up. Lay the stator plate (13) on the stator (15) and line 13.Remove seal.
-
Page 7: Parts List
OSP50 Parts List AUTOMATIC Ref. No. Part No. Description Qty. Ref. No. Part No. Description Qty. 60-000-5 Handle 77-003-1 O-Ring 14981-001-1 Pipe Plug 13349-000-1 Motor, 115V Oil (Purchase locally) .54 gal. 13592-000-1 Motor, 230V 19100A012 Bolt, 5/16-18 x 1-1/4" Lg. 56-036-2 MTR HSG 14974-008-5... - Page 8 OSP50AB Parts List 160-000-5 Handle 205022A088 Pipe Plug 1/4" Oil Fill .54 gal 419100A012 Bolt 5/16 - 18 x 500057-044-5 Power Cord 514974-309-5 Diaphragm 630-021-1 10-32 x 1/2 75502-005-1 Switch Bracket 819-004-1 Screw, 10-24 x 914525A010 Seal 10 19109A070 Jamb Nut 11 33-000-2 Foot &...
- Page 9 Pump Notes ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________...
- Page 10 Pump Notes ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________...
- Page 11 Pump Notes ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________...
-
Page 12: Limited Warranty
LIMITED WARRANTY HYDROMATIC warrants to the original consumer purchaser (“Purchaser” or “You”) of HYDROMATIC Sump Pumps, Effluent Pumps, Sewage Pumps (other than 2-1/2"), and Package Systems, that they will be free from defects in material and workmanship for the Warranty Period of 36 months from date of manufacture. Our warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication, improper installation, or improper maintenance.
