Assembly; Tools Required - CYBEX Plate Loaded 16120 Smith Press Owner's Manual

Tools Required

9/16" Socket wrench
•
7/16" Wrench
•
7/32" Allen wrench
•
9/16" Wrench
•
5/16" Allen wrench
•
16120 Smith Press
Total Weight and Size
380 lbs. inches - 84 W x 54 L x 84 H
173 kg cm - 213 W x 137 L x 213 H
Three people will be required for this procedure.
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate
clearance around each machine to allow for safe use and passage.
1. Read and understand all instructions thoroughly before starting any of the procedures
listed below.
2. Verify you have received the appropriate configuration.
Verify you received the correct color machine that you ordered.
•
Verify you received the appropriate owner's manual.
•
Verify you received the warranty sheet.
•
Cybex Plate Loaded 16120 Smith Press Owner's Manual

Assembly
