- Page 1 Cybex ® Plate Loaded Smith Press Owner’s and Service Manual Strength Systems Part Number 16120-999-4 D www.cybexinternational.com...
- Page 3 Cybex logo are registered trademarks of Cybex International, Inc. DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
-
Page 5: Table Of Contents
Table of Contents 1 Safety Safety......1 Safety Guidelines and Practices ..2 Warning/Caution Decals . -
Page 7: Safety
Cybex Plate Loaded 16120 Smith Press Owner’s Manual 1 - Safety Safety Read the Owner’s Manual carefully before assembling, servicing or using Cybex equipment. WARNING: Serious injury could occur if these safety precautions are not observed: User Safety Precautions • Obtain a medical exam before beginning any exercise program. -
Page 8: Safety Guidelines And Practices
Cybex Plate Loaded 16120 Smith Press Owner’s Manual • Immediately replace worn or damaged components. If unable to immediately replace worn or damaged components then remove from service until the repair is made. NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular maintenance is performed. Safety Guidelines And Practices Cybex recommends that all fi... -
Page 9: Warning/Caution Decals
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Warning/Caution Decals Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death or serious injury. Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor or moderate injury. -
Page 10: Regular Maintenance Activities
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Regular Maintenance Activities Preventative maintenance activities must be performed to maintain normal operation of this equipment. Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative maintenance activities. -
Page 11: Customer Service
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Set Up 1. Adjust bar to appropriate height for exercise. See Diagram A. 2. Adjust bar stops to appropriate height for exercise. See Diagram B. NOTE: Ensure stops are set properly at equal height. 3. -
Page 12: Ordering Parts
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Ordering Parts Fax orders to 508-533-5183. To speak with a customer service representative, call 888-462-9239 (for customers living within the USA) or 508-533-4300 (for customers outside the USA). You may also contact us through e-mail at techhelp@cybexintl.com. -
Page 13: Damaged Parts
Cybex Plate Loaded 16120 Smith Press Owner’s Manual 5. Forward the package through UPS to Cybex. Attn: Customer Service Department Cybex International, Inc. 1975 24th Ave SW Owatonna, MN 55060 NOTE: Merchandise returned without an RMA number on the outside of the package or shipments sent COD will not be accepted by the Cybex receiving department. - Page 14 Cybex Plate Loaded 16120 Smith Press Owner’s Manual 2. Verify you have received the appropriate confi guration. Verify that you received the correct color machine that you ordered. Verify you received the appropriate owner’s manual. Verify you received the warranty sheet. 3.
- Page 15 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Locknut (Qty of 2 each side) Back Frame Mount BHSCS (Qty of 2 both side) Locknut Figure 3 Using a 7/32” Allen wrench and a 9/16” secure back frame mount to frame with the four BHSCS and locknuts from shipping package.
- Page 16 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Locate four Socket Head Cap Screws (SHCS), four washers and loctite from shipping package. Place a small drop of loctite on the four SHCS and in threaded holes of weight bar bracket. See Figure 5. Place washer over SHCS.
-
Page 17: Maintenance
Cybex Plate Loaded 16120 Smith Press Owner’s Manual 5 - Maintenance All preventive maintenance activities must be performed on a regular basis. Performing routine preventive maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment. NOTE: Cybex is not responsible for performing regular inspection and maintenance actions for your machines. - Page 18 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Page 12...
-
Page 19: Service
Cybex Plate Loaded 16120 Smith Press Owner’s Manual 6 - Service Please refer to the next pages for parts lists and exploded-view diagrams NOTE: All inspections and repairs must be performed by trained service personnel only. Cybex will void warranty if non-Cybex replacement parts are used. - Page 20 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Page 14...
-
Page 21: Exploded-View Diagram
Cybex Plate Loaded 16120 Smith Press Owner’s Manual Page 15... - Page 22 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Page 16...
- Page 23 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Page 17...
- Page 24 Cybex Plate Loaded 16120 Smith Press Owner’s Manual Page 18...
- Page 26 10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX 508-533-5183 www.cybexinternational.com • techhelp@cybexintl.com...
