- Page 1 Unlock your vehicles potential www.Hsputelids.com 1300 441 498 Part No: X18 4x4 Accessories Fitting Time: 45mins I S U Z U D - m a x H S P TA I L L O C K F i t t i n g i n s t r u c t i o n s FI Doc Part No: X18 - Issue: 1 - 13/06/18 AU Page 01 of 12...
-
Page 2: General Notes
P a r t s s u p p l i e d Parts Supplied Quality/ CHECK LIST Part Description Part Number Length TAIL LOCK ASSEMBLY Main Bracket X18-A Tube X18-B M10 Bolt x2 M10 Flat Washer x2 M8 Flat Washer x4... - Page 3 S t e p 1 Fit the lever through main braket bend as shown. S t e p 2 Fit tube to lever and fasten the bolt as shown. FI Doc Part No: X18 - Issue: 1 - 13/06/18 Page 03 of 12...
- Page 4 S t e p 3 Fit actuator to main bracket as shown. S t e p 4 Plug wiring to actuator. FI Doc Part No: X18 - Issue: 1 - 13/06/18 Page 04 of 12...
- Page 5 S t e p 5 Remove tail gate cover. S t e p 6 Remove cover then remove the indicated bolts and rod as shown. Dispose cover FI Doc Part No: X18 - Issue: 1 - 13/06/18 Page 05 of 12...
- Page 6 S t e p 7 Fit Tail Lock bracket and indicated bolts and rod as shown. 1) Use the longer of the two bolts removed earlier to fasten. 2) Use the included 20mm M6 Bolt to fasten. S t e p 8...
- Page 7 S t e p 9 Run wiring from tailgate to front passenger door over chassis rail. Cable tie wiring every 500mm. Make an incision and run wiring through floor grommet. Remembering to silicon when finished. S t e p 1 0 REMOVE SCUFF PLATE FI Doc Part No: X18 - Issue: 1 - 13/06/18...
- Page 8 S t e p 1 1 REMOVE HEX NUT REMOVE KICK PANEL S t e p 1 2 REMOVE SCREW MODULE FI Doc Part No: X18 - Issue: 1 - 13/06/18 Page 08 of 12...
- Page 9 S t e p 1 3 Release the lever and unplug wiring. S t e p 1 4 Remove indicated section. FI Doc Part No: X18 - Issue: 1 - 13/06/18 Page 09 of 12...
- Page 10 S t e p 1 5 Remove wire blue, replace with wire blue from X-PATCH loom. Remove wire blue with red trace, replace with wire red from X-PATCH loom S t e p 1 6 House the actuator wiring harness terminals (1) into the supplied 2-way male connector (2) as shown.
- Page 11 S t e p 1 7 Connect X-PATCH loom to CL-LOOM-LONG S t e p 1 8 Plug all connectors removed earlier inside kicker panel. Then assemble kicker panel. FI Doc Part No: X18 - Issue: 1 - 13/06/18 Page 11 of 12...
- Page 12 S t e p 1 9 Place and fasten tail gate cover. F i t t i n g c o m p l e t e d FI Doc Part No: X18 - Issue: 1 - 13/06/18 Page 12 of 12...
