Check contents of kit before commencing fitment and report any discrepancies
IMPORTANT
Care Instructions
Maintenance
Tools Required
Fitting Instructions Part Number
MX40P. Mercedes-Benz X Class
Dual Cab 2017+
• Do not stand/sit or rest heavy objects on Tonneau Cover
• Humans or animals are not to be under the closed Tonneau at any given time
• Securely lock tonneau Cover before operating vehicle
• Tonneau Cover is not dust or water tight
• Do not carry open volatile chemicals with Tonneau Cover installed
• If contact with volatile chemicals occur, clean Tonneau with mild detergent and water solution
• Read Instructions fully before commencing installation.
• Clean Tonneau Cover with a mild detergent and water solution
• Do not use abrasive cleaners or solvents
• Refer to manufactures instructions applicable to power drill.
• Protect Tub floor against scratches during installation process.
If lubrication of the locks or hinges is required use only Graphite Powder. DO NOT use any other
lubricants or oils.
• Pen / Marker
• Centre Punch
• Drill & Drill bits
• Phillips head screwdriver
• Caulking Gun
• Silicon - Non Acetic
• Die Grinder & multi tool
• Masking Tape
• Scissors & Knife
• Ruler
• Spanner & Socket
• Tape measure
MX40P
*Image example shown only
• Soapy water solution
• Allen Key set (Metric)
Page 1 of 16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HSP MX40P
Summary of Contents for HSP MX40P
- Page 1 Fitting Instructions Part Number MX40P. Mercedes-Benz X Class Dual Cab 2017+ Check contents of kit before commencing fitment and report any discrepancies *Image example shown only • Do not stand/sit or rest heavy objects on Tonneau Cover • Humans or animals are not to be under the closed Tonneau at any given time •...
- Page 2 Qty - 12 Qty - 2 Qty - 2 Qty - 8 Qty - 8 Qty - 8 OTHER Fitting Instructions Alcohol wipe Alan key Fitting Instruction Qty - 1 Qty - 1 Qty - 1 MX40P Page 2 of 16...
- Page 3 Installation Steps Flow Chart START TUB PREP FOR LID INSTALL LID INSTALL AND ADJUSTMENT FINISH MX40P Page 3 of 16...
- Page 4 Thoroughly clean installation areas. Important: Instructions are for Utes with an UNDER-RAIL tubliner. If you have an OVER-RAIL tubliner you must trim the top off. Find centre and mark position. MX40P Page 4 of 16...
- Page 5 Measure and mark the positions as indicated above from the centre of the bed for placement of the bottom hinges. WARNING: RECHECK DIMENSIONS TO ENSURE CORRECT MEASURENT 1177 Drive the self-tapping screws through the holes in the top and the base of the hinge plate into the tub. Tighten to 3Nm. MX40P Page 5 of 16...
- Page 6 IMPORTANT: Position extrusion as close to the header rail rear radius. Rub down firmly to ensure maximum adhesion. Important: DO NOT over tighten screws. Recommended tightening torque is 1- 3 Nm MX40P Page 6 of 16...
- Page 7 When lid is aligned correctly, secure the catch hinge to the lid using 4 M8 Thick Washers and M8 Bolts Important: Ensure tongues are fully inserted into the hinge slots with hinge pin securely in place. MX40P Page 7 of 16...
- Page 8 Repeat for the opposite side. Important: If you have purchased a Central Locking Ute Lid please ignore the next page concerning Lock Bracket Installation and Lock Bracket adjustment. MX40P Page 8 of 16...
- Page 9 Part No: 1200 1200 Brace Bracket Choose relevant hole to avoid obstruction. Tighten loosely Align brace bracket against tub inner wall. 1) Screw in using self drilling screw 2) Tighten fully MX40P P40P Page 9 of 14 Page 9 of 16...
- Page 10 Cut off excess cable making sure to leave 20mm from locking allen key bolt. MX40P Page 10 of 16...
- Page 11 MX40P MX40P Page 10 of 16 Page 11 of 16...
- Page 12 MX40P Page 12 of 16...
- Page 13 Wash Hard Tonneau Cover using water and normal carwash detergent and polish with an automo- tive polish. Please ensure Lid is kept locked at all times when not being used, for both safety and longevity. NOTE: Having trouble? Call your Supplier. MX40P Page 13 of 16...
- Page 14 MX40P Page 14 of 16...
- Page 15 MX40P Page 15 of 16...
- Page 16 MX40P Mercedes-Benz X Class Dual Cab MX40P Page 16 of 16...
